Main Technical Parameters
|
Roller Stations
|
13Stations
|
|
Roller & Shaft Material
|
45# Steel Quenching and Plating
|
|
Diameter of Shaft
|
Φ70mm
|
|
Cutter Material
|
CR12
|
|
Drive Type
|
Chain Drive
|
|
Speed
|
15-20m/min
|
|
Total Power
|
4+4KW
|
|
Voltage
|
380V 50Hz3Phases
|
Product Introduction
The 13 Station Color Steel Tile Roll Forming Machine is developed for continuous forming of color steel roofing tile profiles. Steel sheet is guided through the forming section and shaped progressively until the required roofing profile is produced.
This configuration includes 13 roller stations, 45# steel rollers and shafts with quenching and plating treatment, a Φ70mm shaft diameter, and a CR12 cutter. The machine operates with chain drive transmission and a specified production speed of 15–20m/min.
Technical Specifications
| Item |
Specification |
| Roller Stations |
13 Stations |
| Roller & Shaft Material |
45# Steel, Quenching and Plating |
| Shaft Diameter |
Φ70mm |
| Cutter Material |
CR12 |
| Drive Type |
Chain Drive |
| Speed |
15–20m/min |
| Total Power |
4+4KW |
| Voltage |
380V / 50Hz / 3 Phases |
Applications
The machine is suitable for producing:
- Color steel roofing tiles
- Metal roofing profiles
- Roofing sheet panels
- Steel structure building materials
- Construction roofing products
Product Advantages
13-Station Forming Configuration
The forming section uses 13 roller stations to shape the steel sheet progressively and consistently.
Treated 45# Steel Rollers & Shafts
The main forming rollers and shafts use 45# steel with quenching and plating treatment.
CR12 Cutting Component
The machine is equipped with a CR12 cutter according to the specified configuration.
Chain Drive Transmission
The chain drive structure provides mechanical transmission for the forming system.
Continuous Production Capability
With a specified operating speed of 15–20m/min, the machine is configured for continuous roofing profile production.
Manufacturing & Quality
The equipment configuration is established according to the confirmed technical specifications, including forming stations, roller and shaft material, shaft diameter, cutter material, drive type, production speed, total power, and voltage.
Machine components and assembly can be checked against the confirmed specifications before shipment.
Why Choose This Machine?
When selecting roll forming equipment, the finished roofing profile, steel material, forming station quantity, required production speed, cutting configuration, and electrical supply should be considered.
The 13 Station Color Steel Tile Roll Forming Machine provides a specific configuration for manufacturers requiring continuous color steel roofing profile forming.
FAQ
How many roller stations are included?
This model has 13 roller stations.
What material is used for the rollers and shafts?
The rollers and shafts use 45# steel with quenching and plating treatment.
What is the shaft diameter?
The shaft diameter is Φ70mm.
What cutter material is specified?
The cutter uses CR12 material.
What is the production speed?
The specified operating speed is 15–20m/min.
What is the power supply specification?
The machine is specified for 380V / 50Hz / 3 Phases.
