Automatic single-layer metal corrugated sheet rolling machine - Roof tile manufacturing rolling forming machine - Industrial equipment

Main Technical Parameters

Product Introduction

The 12 Station Color Steel Tile Roll Forming Machine is designed to process steel sheets into continuous roofing tile profiles. The material moves through the forming section in sequence, with each roller station contributing to the final profile shape.

The machine configuration includes 12 roller stations, 45# steel rollers and shafts with quenching and plating treatment, a Φ70mm shaft, and a CR12 cutter. A chain drive system is used for transmission, with a specified production speed of 15–20m/min.

Technical Specifications

Applications

The machine is suitable for:

• Color steel tile manufacturing
• Metal roofing profile production
• Roofing sheet processing
• Steel structure construction materials
• Building roof panel manufacturing

Product Advantages

Progressive Profile Forming
The 12 roller stations work through successive forming stages to shape the steel sheet into the required roofing profile.

Processed 45# Steel Components
The rollers and shafts are specified as 45# steel with quenching and plating treatment.

CR12 Cutting System
The cutting section uses CR12 material according to the supplied machine specification.

Chain Drive Transmission
The equipment uses chain transmission to transfer mechanical power through the forming system.

Continuous Working Configuration
The specified speed of 15–20m/min is suitable for continuous roofing profile forming operations.

Manufacturing & Quality

The machine is configured around the confirmed technical parameters, including the number of roller stations, roller and shaft material, shaft diameter, cutter material, drive method, production speed, total power, and voltage.

The machine configuration can be inspected during assembly and before shipment according to the confirmed technical requirements.

Why Choose This Machine?

A suitable roofing roll forming machine should be selected according to the required profile, raw material, forming station configuration, production speed, cutting requirements, and local electrical conditions.

This 12 Station Color Steel Tile Roll Forming Machine provides a defined equipment configuration for continuous color steel roofing profile production.

FAQ

How many roller stations does this model have?
It is equipped with 12 roller stations.

What are the roller and shaft specifications?
The rollers and shafts use 45# steel with quenching and plating treatment.

What is the shaft diameter?
The shaft diameter is Φ70mm.

What material is used for the cutter?
The cutter material is CR12.

What is the operating speed?
The specified speed is 15–20m/min.

What is the electrical configuration?
The machine is specified for 380V / 50Hz / 3 Phases.
