High Efficiency Gear-Driven Trapezoid Steel Sheet Roll Forming Machine

Main Technical Parameters

Product Overview

Forming Performance

The sheet material is progressively shaped as it moves through the forming rollers. Each roller station contributes to the development of the final roofing profile, providing a continuous forming process rather than a single-stage operation.

The specified production speed for this configuration is 15–20m/min.

Component Details

45# Steel Forming Parts
The rollers and shafts are specified as 45# steel, processed with quenching and plating treatment.

Φ70mm Shaft
The forming assembly uses a Φ70mm diameter shaft.

CR12 Cutter
The cutting section is configured with CR12 cutter material.

Chain Drive
Mechanical transmission is provided through a chain drive system.

Where It Can Be Used

This type of roll forming equipment can be applied to the production of:

• Color steel roofing tiles
• Metal roofing profiles
• Roofing sheet panels
• Steel building components
• Construction roof materials

Production & Power Requirements

The machine specifications include:

• 12 forming stations
• 15–20m/min production speed
• 4+4KW total power
• 380V / 50Hz / 3 Phases

The electrical supply should be matched with the installation site's available power conditions.

Configuration Guidance

The final forming configuration should be selected according to the required roofing profile and material specifications. For customized equipment, providing a profile drawing or finished sample can help confirm the appropriate forming arrangement.

FAQ

What is the station quantity of this machine?
The specified configuration contains 12 roller stations.

What treatment do the rollers and shafts receive?
They are made from 45# steel with quenching and plating treatment.

What is the shaft size?
The shaft diameter is Φ70mm.

Which cutter material is specified?
The cutter material is CR12.

How does the machine transmit power?
It uses a chain drive system.

What is the specified production speed?
The machine operates at 15–20m/min according to the supplied specification.
