Export Standard Steel Sheet Roof Tile and Wall Panel Roll Forming Making Machine

Export Standard Steel Sheet Roof Tile and Wall Panel Roll Forming Making Machine
Export Standard Steel Sheet Roof Tile and Wall Panel Roll Forming Making Machine Export Standard Steel Sheet Roof Tile and Wall Panel Roll Forming Making Machine Export Standard Steel Sheet Roof Tile and Wall Panel Roll Forming Making Machine Export Standard Steel Sheet Roof Tile and Wall Panel Roll Forming Making Machine Export Standard Steel Sheet Roof Tile and Wall Panel Roll Forming Making Machine

Large Image :  Export Standard Steel Sheet Roof Tile and Wall Panel Roll Forming Making Machine

Product Details:
Place of Origin: China
Brand Name: HC
Certification: CE
Model Number: 24-144-914-1220
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: 40GP Container
Delivery Time: 30days
Payment Terms: L/C,T/T
Supply Ability: 60 Sets Per Month

Export Standard Steel Sheet Roof Tile and Wall Panel Roll Forming Making Machine

Description
Panel Thickness: 0.3-0.6mm Motor Power: 4+4KW
Machine Frame: 350 H Beam Cutting Method: Hydraulic Cutting
Decoiler Type: Hydraulic/manual Decoiler Roller Material: 45# Steel
Machine Type: Roll Forming Machine Production Capacity: 15-20m/min

Main Technical Parameters

Roller Stations

 20Stations

Roller & Shaft Material

45# Steel Quenching and Plating

Diameter of Shaft

Φ70mm

Cutter Material

CR12

Drive Type

Chain Drive

Speed

15-20m/min

Total Power

4+4KW

Voltage

380V 50Hz3Phases

3. Forming Section: Twenty Progressive Stages

The 20 roller stations form the core of the machine. During operation, the metal strip moves through the forming section, where successive rollers gradually shape it into the required roofing profile.

This progressive process is designed around the selected roller configuration. The finished sheet profile depends on the machine's forming roller design.

4. Mechanical Components

Roller and Shaft Assembly

The rollers and shafts are specified as 45# steel with quenching and plating. The shaft diameter is Φ70mm.

CR12 Cutting System

The machine uses CR12 material for its cutter. The cutting section separates the formed roofing sheet according to the required production length.

Chain Drive Transmission

Chain drive is used to transfer mechanical power through the machine's forming system.

Power Configuration

The total power specification is 4+4KW. The electrical supply requirement is 380V, 50Hz, three phases.

5. Production Sequence

The machine operates through the following stages:

  • Material Input: Metal material enters the feeding section.

  • Roller Forming: The sheet passes through 20 forming stations.

  • Profile Development: The rollers progressively shape the material into the selected roofing design.

  • Cutting Operation: The CR12 cutter separates the formed sheet.

  • Product Output: Finished panels are collected for further processing or installation.

6. Possible Application Fields

With the appropriate roller profile, the machine can be used for manufacturing metal roofing sheets for:

  • Industrial buildings and manufacturing facilities

  • Commercial construction projects

  • Residential roofing systems

  • Warehouses and logistics buildings

  • Agricultural structures

The required sheet profile and dimensions should be confirmed before machine production.

7. Questions and Answers

Q: What is the number of roller stations?
A: This model has 20 roller stations.

Q: What material is used for the roller and shaft components?
A: They use 45# steel with quenching and plating.

Q: What is the shaft diameter?
A: The specified diameter is Φ70mm.

Q: Which material is used for cutting?
A: The cutter material is CR12.

Q: What transmission method does the machine adopt?
A: It uses chain drive transmission.

Q: How fast does the machine operate?
A: The specified speed is 15–20m/min.

Q: What electrical specifications should buyers prepare for?
A: The machine requires 380V, 50Hz, 3 phases, with total power of 4+4KW.

8. SEO Metadata

SEO Title: 20 Station Color Steel Tile Roll Forming Machine

Meta Description: 20 station color steel tile roll forming machine with 45# steel rollers and shafts, quenching and plating, Φ70mm shaft, CR12 cutter, chain drive, and 15–20m/min speed.
