Trilobal metal rolling machine for forming wall panels and roof panels into a trapezoidal shape

Description
Panel Thickness: 0.3-0.6mm Motor Power Data: 4+4KW
Machine Frame: 350 H Beam Cutting Method Type: Hydraulic Cutting
Decoiler Type: Hydraulic/manual Decoiler Roller Material: 45# Steel
Machine: Roll Forming Machine Production Capacity: 15-20m/min
Color: Customized

Main Technical Parameters

Number of Forming Stations

 16Stations

Roller & Shaft Material

45# Steel Quenching and Plating

Diameter of shaft

Φ70mm

Cutting Blade Material

CR12

Drive Type

Chain Drive

Operating Speed

15-20m/min

Total Power data

4+4KW

Voltage

380V 50Hz3Phases

3. Sixteen-Station Forming Configuration

The machine uses 16 roller stations to shape metal sheets progressively rather than forming the entire profile in a single operation.

As the material passes through each station, the rollers gradually create the required profile shape. The multi-stage forming arrangement is designed to support continuous processing and maintain the intended profile geometry.

The final roller configuration should be matched to the customer's required product drawing.

4. Mechanical Components and Features

45# Steel Rollers with Quenching and Plating

The rollers and shafts are made from 45# steel and receive quenching and plating treatment. This is the specified material and surface-treatment configuration for the forming components.

Φ70mm Shaft Diameter

The machine uses shafts with a diameter of Φ70mm, forming part of the roller support and transmission structure.

Chain Drive Transmission

A chain drive system transfers power through the machine's transmission mechanism to operate the forming section.

CR12 Cutter Material

The cutter is made from CR12 material, as specified in the machine configuration.

4+4KW Total Power

The machine's stated total power is 4+4KW, providing the power configuration for its production operation.

5. Production Workflow

The roll forming process generally follows these stages:

  1. Material Feeding: The metal sheet enters the forming section.

  2. Progressive Forming: The material passes through 16 roller stations.

  3. Profile Shaping: Each station contributes to gradually forming the required profile.

  4. Cutting: The cutter separates the formed material to the required length according to the machine setup.

  5. Finished Product Handling: The completed profiles are collected for further processing or packaging.

6. Electrical Configuration

The machine is specified with the following electrical parameters:

  • Total Power: 4+4KW

  • Voltage: 380V

  • Frequency: 50Hz

  • Phase: 3 Phases

Before installation, buyers should confirm that the machine's electrical requirements are compatible with the power supply available in their workshop.

7. Frequently Asked Questions

Q1: How many roller stations does this machine have?
It is equipped with 16 roller stations.

Q2: What material is used for the rollers and shafts?
Both are made of 45# steel with quenching and plating treatment.

Q3: What is the shaft diameter?
The specified shaft diameter is Φ70mm.

Q4: What is the drive system?
The machine uses chain drive transmission.

Q5: What material is used for the cutter?
The cutter material is CR12.

Q6: What is the production speed?
The specified speed is 15–20 meters per minute.

Q7: What voltage is required?
The electrical specification is 380V, 50Hz, 3 phases.

8. SEO Title and Meta Description

SEO Title:
16 Station Roll Forming Machine with Chain Drive and CR12 Cutter

Meta Description:
Discover a 16 station roll forming machine featuring 45# steel quenched and plated rollers and shafts, Φ70mm shafts, chain drive, CR12 cutter material, and 15–20m/min speed.

SEO Keywords:

  • 16 station roll forming machine

  • Chain drive roll forming machine

  • Metal profile forming equipment

  • CR12 cutter roll forming machine

  • Φ70mm shaft roll forming machine

  • 45# steel roller forming machine

  • Industrial metal sheet forming machine
