1050mm Automatic Type Glazed Tile Cold Roll Forming Machine

Product Description

Color steel glazed tiles are suitable for various types of buildings, including industrial buildings, residential buildings, commercial buildings, etc. In industrial buildings, they can be used as factory roof and wall materials, with good waterproof and windproof performance

Main Technical Parameters

Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
In the production process of glazed tiles, metal sheets are usually supplied in the form of coils. The primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.

Hydraulic Pump Station

When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.

In the cutting process, the hydraulic pump station pushes the cutting tool to move quickly and forcefully, accurately cutting the formed floor deck to the set length.

Touch Screen Control Cabinet

Shaft & Roller
