Product Details:
|
| Material Type: | PPGI/GI | Material Thickness: | 0.3-0.6mm |
|---|---|---|---|
| Material Width: | 1250mm | Roller Stations: | 15Stations |
| Diameter Of Shaft: | Φ70mm | Cutter Material: | CR12 |
| Drive Type: | Chain Drive | Speed: | 4m/min |
| Total Power: | 5.5+5.5KW | Voltage: | 380v 50Hz 3phases |
| Highlight: | Aluminium Glazed Tile Roll Forming Machine,Step Glazed Tile Roll Forming Machine,Aluminium Step Glazed Tile Forming Machine |
||
Product Description
The main body of the equipment is made of high-strength high-quality steel. After rigorous quality testing and careful structural optimization, it has excellent rigidity and stability. In long-term, high-intensity production operations, it can continue to operate stably, effectively reduce the occurrence of equipment failures, reduce maintenance costs, and ensure production continuity.
Main Technical Parameters
| Material | Type | PPGI/GI |
| Thickness | 0.3-0.6mm | |
| Width | 1250mm | |
| Roller Stations | 15Stations | |
| Roller & Shaft Material | 45# Steel Quenching and Plating | |
| Diameter of Shaft | Φ70mm | |
| Cutter Material | CR12 | |
| Drive Type | Chain Drive | |
| Speed | 4m/min | |
| Total Power | 5.5+5.5KW | |
| Voltage | 380V 50Hz 3Phases | |
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
Able to accommodate a variety of metal coils of different specifications, including different widths, thicknesses and materials
Hydraulic Pump Station
When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
The control cabinet can be interconnected with other equipment, such as working with the uncoiler, hydraulic pump station, etc., to ensure the efficient and stable operation of the entire floor decking forming machine system, providing a strong guarantee for the production of high-quality floor decking.
Feeding Table & Pre-Cutter
The feeding table also has a certain buffering function. When there is a short speed fluctuation in the upstream uncoiler or downstream forming equipment, the feeding table can maintain the continuity of material transportation through its own buffering mechanism to avoid production stagnation or sheet damage caused by speed differences.
Shaft & Roller
Material is 45# Steel Quenching and Plating.
The processed rollers are smooth, hard and will not rust.
Will not leave any scratches on the sheet when working.
Inside the molding machine, multiple shafts cooperate with each other to support the rollers and other components, ensuring that they maintain a stable position and posture during operation.
Pressing Section & Cutter
The material of blade is CR12.
With high strength, better hardenability and good wear resistance.
The reliability and durability of the cutter are also important factors affecting production stability. Carefully designed and manufactured cutters can maintain good cutting performance in long-term, high-intensity working environments, reducing the frequency of downtime and replacement due to cutter wear and damage, thereby reducing production costs and improving the company's production efficiency.
The main body of the equipment is made of high-strength high-quality steel. After rigorous quality testing and careful structural optimization, it has excellent rigidity and stability. In long-term, high-intensity production operations, it can continue to operate stably, effectively reduce the occurrence of equipment failures, reduce maintenance costs, and ensure production continuity.
