Product Description
Construction industry: widely used in roof and wall decoration of various industrial and civil buildings, such as factories, warehouses, houses, villas, gymnasiums, exhibition halls, theaters, etc., which can not only play the role of waterproofing and heat insulation, but also increase the beauty and artistic value of the building.
Antique building restoration and new construction: In the restoration and new construction of antique buildings, the colored steel glazed tiles produced by the glazed tile press can replace the traditional ceramic glazed tiles, retain the style and charm of ancient buildings, and solve the problems of traditional glazed tiles being fragile, easy to fade, and high maintenance costs.
Garden landscape architecture: used for the roof decoration of pavilions, corridors, archways and other garden landscape buildings in parks, squares, scenic spots and other places, creating an antique atmosphere and complementing the natural environment.
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Main Technical Parameters
| Material |
Type |
PPGI/GI |
| Thickness |
0.3-0.6mm |
| Width |
1000mm |
| Roller Stations |
12Stations |
| Roller & Shaft Material |
45# Steel Quenching and Plating |
| Diameter of Shaft |
Φ70mm |
| Cutter Material |
CR12 |
| Drive Type |
Chain Drive |
| Speed |
2-4m/min |
| Total Power |
5.5+5.5KW |
| Voltage |
380V 50Hz 3Phases |
5T Manual Decoiler
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
(adjustable according to demand.)
In order to avoid damage to the machine by impact when the machine is running, we have installed a brake device for you.
Shaft & Roller
Material is 45# Steel Quenching and Plating.
The processed rollers are smooth, hard and will not rust.
Will not leave any scratches on the sheet when working.
Feeding Table & Pre-Cutter
Guide the coil come into the correct position and going to the roll forming part.
Also including a Hand Pull Cutting Device, it is convenient to pre-cut the coil when want to changing color or thickness.
Pressing Section & Cutter
The material of blade is CR12.
With high strength, better hardenability and good wear resistance.
Hydraulic Pump Station
The purpose of this pump station is to drive the cutter to start cutting works.
The hydraulic tank use 46# hydraulic oil.
Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.
Solenoid valve brand: Huade
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Electrical Component Brand:
1. VFD: Delta
2. Circuit breaker: Delixi
3. Contactor: Delixi
4. Relay: Xinling
5. PLC: Delta
6. Transformer: Delixi
