Roofing Sheet 0.6mm Step Tile Roll Forming Machine Chain Drive

Roofing Sheet 0.6mm Step Tile Roll Forming Machine Chain Drive
Roofing Sheet 0.6mm Step Tile Roll Forming Machine Chain Drive Roofing Sheet 0.6mm Step Tile Roll Forming Machine Chain Drive

Large Image :  Roofing Sheet 0.6mm Step Tile Roll Forming Machine Chain Drive

Product Details:
Place of Origin: Botou Hebei China
Brand Name: HC
Certification: ISO
Model Number: HC29-185-925
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month

Roofing Sheet 0.6mm Step Tile Roll Forming Machine Chain Drive

Type: Chain Drive Tile Roll Forming Machine Thickness: 0.3-0.6mm
Width: 1250mm Warranty: 1 Year
Dimension: 6.7*1.6*1.3m Equipment Base: 300H Steel Frame
High Light:

0.6mm step tile roll forming machine


1250mm step tile roll forming machine


chain drive glazed roll forming machine

Maintenance of Steel Glazed Tile Roll Forming Machine

Daily maintenance plays an very importance role in extending the operation time and of roof color steel tile roll forming machine and the good quality finished roof tiles. The following points should be part of the machine's daily production and usage routine.

  • Regularly lubricated the outside parts of the glazed roof tile roll forming machine, such as the driving chain...
  • Regularly brush the surface of roller, particularly when working outside. If you do not use the color steel roof tile roll forming machine in a long time, you should apply luricating oil on the roller surface, make sure you clean it for next time running machine.
  • If the roof tile roll forming machine is not operated in a long period, should cover it with plastic film, to avoid getting rain or dust on the machine, or avoid the machine becoming dampt, especially the PLC electric control board.
  • Make sure the cutting system is lubricated when necessary.
  • Check the Hydraulic station often and the oil quantity of the deceleration machines, add more oil if the oil level is low.
  • Check the electric appliances box and every leads conjuction circumstance of the trapezoidal roof roll forming machine.

Technical Parameters

No Item Parameter Remark




Type Color Steel
Width(mm) 1200 According to customer's requirement
Thickness(mm) 0.3-0.8 According to customer's requirement
Yield Strength(Mpa) 230-300 According to customer's requirement
2 Forming Speed(m/min) 2-4 Including Punching
3 Roller Material No.45 steel with hard chromized
4 Cutting Model Hydraulic Cutting According to customer's requirement
5 Power source Type 380V/3PH/50HZ According to customer's requirement

Components of the machine

No Name Quantity Remarks
1 Decoiler   1set Up to customer
2 Main Machine Pre-cutting Device 1set Up to customer
Feeding Device 1set
Roll Forming 1set
Punching Die and Post-cutting 1set
Hydraulic System 1set
3 Electric Control System 1set
4 Supporter/Automatic Stacker 1set

Up to customer


Superior Colored Steel Roof Glazed Tile Roll Forming Machine 1 Year Warranty

This high speed European standard monterrey glazed tile roll forming machine is the special equipment for continuous rolling and cold-forming on steel sheet. It adopts coiling steel sheet as the raw material, decoiling the coil, continuous rolling and cold-forming, automatically cut to the size and output the finished panel. The equipment adopts PLC control, AC frequency and adjusting the speed technology, and it realizes the continuous automatically production, therefore, it is really a new type of energy-saving and high-effective producing equipment for steel structure.
