High-quality steel plate roof and wall panel manufacturing machine, with long service life, suitable for industrial building construction.

Description
Sheet Thickness: 0.3-0.6mm Motor Power: 4+4KW
Condition: New Machine Frame: 350 H Beam
Cutting Method: Hydraulic Cutting Decoiler: Hydraulic/manual Decoiler
Roller Material: 45# Steel Machine Type: Roll Forming Machine
Production Speed: 15-20m/min

Main Technical Parameters

Roller Stations

 16Stations

Roller ;Shaft Material

45# Steel Quenching and Plating

Shaft Diameter

Φ70mm

Cutter Material

CR12

Drive System

Chain Drive

Machine Speed

15-20m/min

Total Power

4+4KW

Voltage

380V 50Hz3Phases

Product Overview

The Wall Panel Roll Forming Machine is a highly efficient industrial solution engineered for manufacturing wall panels used across diverse construction applications. The 16-Station Color Steel Tile Roll Forming Machine is designed for continuous roll forming of color steel roofing tile profiles. The machine is equipped with a 16-station roller system, allowing the metal sheet to be shaped through a series of progressive forming operations.

16-Station Forming Arrangement

The machine is configured with 16 roller stations in the forming section. During operation, the sheet material passes through the roller groups in sequence, with each station participating in the progressive shaping process.

The number of forming stations is an important specification when selecting equipment for different color steel tile profile requirements.

Roller and Shaft Specifications

The machine uses 45# steel for both rollers and shafts.

The components are processed with quenching and plating treatment, and the forming system adopts a Φ70 mm shaft diameter. These specifications define the main material and structural configuration of the machine.

Chain Drive Transmission

The equipment is equipped with a chain drive system.

This transmission method forms part of the machine's mechanical structure and can be evaluated together with the forming station quantity, shaft specification, and production speed when comparing roll forming equipment.

Cutting System

The cutting section is configured with a CR12 cutter.

The cutter material is one of the technical specifications of the machine and should be considered according to the requirements of the finished color steel tile profile.

Production Speed and Power Requirements

The machine has a specified operating speed of 15–20 m/min.

The total power configuration is 4+4 kW, and the required electrical supply is 380 V / 50 Hz / 3 Phases. The installation environment should provide a matching power supply before machine operation.

Application

The 16-Station Color Steel Tile Roll Forming Machine is intended for continuous production of color steel roofing tile profiles.

Typical applications include:

  • Color steel tile production
  • Metal roofing profile forming
  • Steel sheet profile manufacturing
  • Roofing material processing
  • Building roofing profile production

The suitable machine configuration should be confirmed according to the required product profile and production conditions.

Main Configuration Overview

The machine configuration includes:

  • 16 roller stations
  • 45# steel rollers and shafts
  • Quenching and plating treatment
  • Φ70 mm shaft diameter
  • CR12 cutter
  • Chain drive system
  • 15–20 m/min production speed
  • 4+4 kW total power
  • 380 V / 50 Hz / 3-Phase electrical supply

These specifications provide a technical reference for buyers evaluating a 16-Station Color Steel Tile Roll Forming Machine for continuous roofing profile production.
