Automatic Double Layer Glazed Tile and Ibr Roofing Panel Roll Forming Machine

Large Image : Automatic Double Layer Glazed Tile and Ibr Roofing Panel Roll Forming Machine

Product Details:

Place of Origin:	China
Brand Name:	HC
Certification:	CE
Model Number:	24-18-1250

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	40GP Container
Delivery Time:	30days
Payment Terms:	L/C,T/T
Supply Ability:	60 Sets Per Month

Contact Now

Automatic Double Layer Glazed Tile and Ibr Roofing Panel Roll Forming Machine

Description

Panel Thickness:	0.3-0.6mm	Motor Power:	4+4KW
Machine Frame:	350 H Beam	Cutting Method:	Hydraulic Cutting
Decoiler Type:	Hydraulic/manual Decoiler	Roller Material:	45# Steel
Machine Type:	Roll Forming Machine	Production Capacity:	15-20m/min

Main Technical Parameters

Roller Stations	Upper Layer: 12Stations Down Layer: 15Stations
Roller & Shaft Material	45# Steel Quenching and Plating
Diameter of Shaft	Φ70mm
Cutter Material	CR12
Drive Type	Chain Drive
Speed	15-20m/min
Total Power	4+4KW
Voltage	380V 50Hz3Phases

Our Roll Forming Machine is an high-efficiency manufacturing solution designed to produce the world's most popular architectural roof profiles. Engineered for versatility, this heavy-duty production line seamlessly processes raw metal coils—including PPGI, PPGL, galvanized steel, and aluminum—into precision-contoured trapezoidal sheets, classic corrugated waves, and elegant glazed step tiles. By combining robust mechanical structural engineering with intelligent PLC automation, this machine eliminates the need for multiple single-purpose lines, maximizing your factory floor space and delivering a rapid, substantial return on investment.
