Main Technical Parameters
|
Roller Stations
|
11Stations
|
|
Roller ; Shaft Material
|
45# Steel Quenching and Plating
|
|
Diameter of Shaft
|
Φ70mm
|
|
Cutter Material
|
CR12
|
|
Drive Type
|
Chain Drive
|
|
Product Speed
|
15-20m/min
|
|
Total Power
|
4+4KW
|
|
Voltage
|
380V 50Hz3Phases
|
Product Overview
The Wall Panel Roll Forming Machine is a highly efficient industrial solution engineered for manufacturing wall panels used across diverse construction applications. The 11-Station Color Steel Tile Roll Forming Machine is configured for the continuous production of color steel roofing tile profiles. The machine adopts an 11-station roller forming system, where the metal sheet is shaped progressively through the forming section.
Forming Station Structure
The machine is equipped with 11 roller stations arranged in the forming section. The steel material passes through each station in sequence, allowing the profile to be formed gradually during the roll forming process.
The number of roller stations is an important specification when selecting a machine for different color steel tile profile requirements.
Roller and Shaft Material
The forming rollers and shafts are manufactured from 45# steel.
The specified treatment process includes quenching and plating. The machine uses a Φ70 mm shaft diameter, which defines the main dimensional specification of the forming structure.
Drive System and Cutter Configuration
The machine adopts a chain drive system for transmission.
The cutting unit is equipped with a CR12 cutter. These components represent the main transmission and cutting configuration of the equipment.
Production Speed
The machine provides a specified operating speed of 15–20 m/min.
This speed specification can be used as a reference when evaluating production requirements and comparing different roll forming machine configurations.
Power Supply Requirements
The machine has a total power specification of 4+4 kW.
The required electrical supply is 380 V / 50 Hz / 3 Phases. The installation location should provide a suitable power connection according to the machine requirements.
Application Areas
The 11-Station Color Steel Tile Roll Forming Machine is designed for continuous forming of color steel roofing tile profiles.
Typical application fields include:
- Color steel tile manufacturing
- Metal roofing profile production
- Roofing sheet forming
- Steel profile processing
- Building roofing material production
The machine configuration should be selected according to the required profile specifications and production conditions.
Configuration Summary
The equipment includes:
- 11 roller stations
- 45# steel rollers and shafts
- Quenching and plating treatment
- Φ70 mm shaft diameter
- CR12 cutter material
- Chain drive transmission
- 15–20 m/min operating speed
- 4+4 kW total power
- 380 V / 50 Hz / 3-Phase voltage
These specifications provide a clear technical reference for buyers evaluating an 11-Station Color Steel Tile Roll Forming Machine for roofing profile production.
