The Wall Panel Roll Forming Machine is a highly efficient industrial solution engineered for manufacturing wall panels used across diverse construction applications. The 11-Station Color Steel Tile Roll Forming Machine is designed for the continuous production of color steel roofing tile profiles. Equipped with an 11-station roller forming system, the machine processes the steel sheet through multiple forming stages to create the required profile shape.

Forming System

The machine is equipped with 11 roller stations arranged in the forming section. During the roll forming process, the steel material passes through each station in order, allowing the profile to be formed gradually.

The roller station quantity is an important equipment specification and should be considered according to the required color steel tile profile.

Roller and Shaft Material

The forming rollers and shafts are manufactured from 45# steel.

According to the supplied specifications, these components are treated with quenching and plating. The forming system uses a Φ70 mm shaft diameter, providing a defined structural parameter for the machine.

Drive and Cutting Configuration

The machine uses a chain drive system for transmission.

The cutting section is equipped with a CR12 cutter. The drive type and cutter material are key parts of the machine configuration and can be reviewed together with the forming requirements.

Operating Speed

The specified working speed of this machine is 15–20 m/min.

This parameter provides a reference for production planning and equipment evaluation. The actual production process may depend on the selected profile and operating conditions.

Power Supply

The machine is configured with 4+4 kW total power.

The required electrical specification is 380 V / 50 Hz / 3 Phases. The available power conditions at the installation location should be confirmed before machine operation.

Application Range

The 11-Station Color Steel Tile Roll Forming Machine is intended for continuous forming of color steel roofing tile profiles.

It can be applied in areas such as:

• Color steel tile manufacturing
• Roofing profile forming
• Metal sheet profile production
• Roofing material processing
• Building profile manufacturing

The final machine configuration should correspond with the required finished profile and production requirements.

Machine Configuration Summary

This equipment features an 11-station roller forming section, 45# steel rollers and shafts with quenching and plating treatment, and a Φ70 mm shaft.

The machine is also configured with a CR12 cutter, chain drive transmission, 15–20 m/min forming speed, 4+4 kW total power, and a 380 V / 50 Hz / 3-Phase electrical system.

These specifications provide a technical reference for customers evaluating an 11-Station Color Steel Tile Roll Forming Machine for color steel roofing profile production.
