8-10m / Min Metal Roof Panel Double Layer Roll Forming Machine Automatic Type

Large Image : 8-10m / Min Metal Roof Panel Double Layer Roll Forming Machine Automatic Type

Product Details:

Place of Origin:	Botou Hebei China
Brand Name:	HC
Certification:	ISO/CE
Model Number:	HC35-50

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	15000-39000USD
Packaging Details:	Main machine is nude,the computer control box is packed by carton box
Delivery Time:	30days
Payment Terms:	30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability:	20 sets/month

Contact Now

8-10m / Min Metal Roof Panel Double Layer Roll Forming Machine Automatic Type

Description

Model Number::	Roll Forming Machine	Warranty:	1 Year
Control System:	PLC Control	Cutting Method:	Hydraulic Cut
Working Speed:	8-10m/min	Per Month:	30 Sets
Highlight:	sheet metal roll forming machines , corrugated roll forming machine

8-10m / Min Metal Roof Panel Double Layer Roll Forming Machine Automatic Type

1:Product Description:

Double layer metal roof panel roll forming machine

Application:

Agricultural Warehouses l Garages l Sheds l Hygienic Greenhouses l Sun housesl Pool enclosures l Parksl Porches l Verandas l Sun decks cladding l Chemical & pharmaceutical plants l Livestock structures l Walkway coverings l DIY (Do-It-Yourself) jobs

8-10m / Min Metal Roof Panel Double Layer Roll Forming Machine Automatic Type 0

The details information of double layer metal roof panel roll forming machine

Shaft material	45# steel with tempering, shaft diameter 70mm
Roller material	45# steel with chromeing plating
Roller station	13+15 stands or as your need
Forming speed	8--15m/min
Main motor power	4kw
Main frame	350mm H steel
Chromium plated roller surface	0.05mm
Voltage	380v 50hz 3-phase

The process of double layer metal roof panel roll forming machine :
