20M/Min Metal Roof Panel Double Layer Roll Forming Machine Automatic Type

1set
MOQ
20M/Min Metal Roof Panel Double Layer Roll Forming Machine Automatic Type
Features Gallery Product Description Request A Quote
Features
Specifications
Highlight:

sheet metal roll forming machines

,

corrugated roll forming machine
Basic Infomation
Place of Origin: Botou Hebei China
Brand Name: HC
Certification: CE
Model Number: HC30/28
Payment & Shipping Terms
Packaging Details: Main machine is nude, the computer control box is packed by carton box.
Delivery Time: 30days
Payment Terms: L/C,T/T
Supply Ability: 20 sets/month
Product Description

1:Product Description:


Double layer metal roof panel roll forming machine

Application:

Agricultural Warehouses l Garages l Sheds l Hygienic Greenhouses l Sun housesl Pool enclosures l Parksl Porches l Verandas l Sun decks cladding l Chemical & pharmaceutical plants l Livestock structures l Walkway coverings l DIY (Do-It-Yourself) jobs.


The details information of double layer metal roof panel roll forming machine

Shaft material 45# steel with tempering, shaft diameter 70mm
Roller material 45# steel with chromeing plating
Roller station 11+12 stands or as your need
Forming speed 15-20m/min
Main motor power 4+4kw
Main frame 350mm H steel
Chromium plated roller surface 0.05mm
Voltage 380v 50hz 3-phase

The process of double layer metal roof panel roll forming machine :
20M/Min Metal Roof Panel Double Layer Roll Forming Machine Automatic Type 0
