Zinc Corrugated Roof Wall Iron Sheet Making Roll Forming Machine with Factory Price

Large Image : Zinc Corrugated Roof Wall Iron Sheet Making Roll Forming Machine with Factory Price

Product Details:

Place of Origin:	China
Brand Name:	HC
Certification:	CE
Model Number:	840-900

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	40GP Container
Delivery Time:	30days
Payment Terms:	L/C,T/T
Supply Ability:	60 Sets Per Month

Contact Now

Zinc Corrugated Roof Wall Iron Sheet Making Roll Forming Machine with Factory Price

Description

Panel Thickness:	0.3-0.6mm	Motor Power:	4+4KW
Machine Frame:	350 H Beam	Cutting Method:	Hydraulic Cutting
Decoiler Type:	Hydraulic/manual Decoiler	Roller Material:	45# Steel
Machine Type:	Roll Forming Machine	Production Capacity:	15-20m/min

Main Technical Parameters

Roller Stations	Upper Layer: 12Stations Down Layer: 15Stations
Roller & Shaft Material	45# Steel Quenching and Plating
Diameter of Shaft	Φ70mm
Cutter Material	CR12
Drive Type	Chain Drive
Speed	15-20m/min
Total Power	4+4KW
Voltage	380V 50Hz3Phases

Product Overview

The Wall Panel Roll Forming Machine is an essential, high-efficiency solution designed for the modern construction and metal fabrication industries. Engineered to convert flat metal coils—such as galvanized steel, PPGI, or aluminum—into high-quality, precision-engineered wall cladding and siding panels, this machine combines robust structural engineering with advanced automation.

Applications

The panels produced by this line are widely utilized in industrial workshops, commercial warehouses, prefabricated houses, and agricultural buildings due to their excellent weather resistance, structural strength, and aesthetic appeal. With a modular design, the machine can be customized to produce various profiles, including corrugated, trapezoidal, or concealed-joint wall panels, making it an indispensable asset for maximizing production capacity and achieving a rapid return on investment.

Key Features

Product Name: Wall Panel Roll Forming Machine

Machine Type: Roll Forming Machine

Roller Material: High-quality 45# Steel for durability and precision

Shaft Material: 45# Steel ensuring strength and long service life

Machine Frame: Robust 350 H Beam frame for stability and support

Decoiler Type: Available with Hydraulic or manual Decoiler options

Suitable for manufacturing hanging board roll forming machine panels

Ideal for producing wall roll forming machine components

Capable of forming sliding roll forming machine elements efficiently
