Designed for maximum space efficiency and versatile manufacturing, our Heavy-Duty Double Layer Roof Tile Roll Forming Machine integrates two independent production lines into a single compact frame. It allows manufacturers to produce two distinct tile profiles—wave-shaped colored roof panels and trapezoidal sheets—without changing roller tools.

Certified with international CE standards, this automated forming system utilizes high-precision 45# steel quenched rollers and a robust chain drive, achieving stable production speedsof 15–20 m/min with superior structural rigidity.

Key Advantages & Engineering Excellence

• Dual-Profile Space-Saving Design: Combines upper and lower forming stations on one machine frame, effectively cutting factory space requirements in half and reducing equipment investment costs.

• High-Precision Quenched Rollers: Features 45# steel rollers with hard chrome plating and Φ70mm solid shafts to ensure long-term wear resistance, accurate wave geometry, and smooth sheet feeding.

• Durable Cr12 Hydraulic Cutter: Equipped with a precision Cr12 mold steel cutting blade that delivers clean, burr-free post-cutting with zero profile deformation.

• Sturdy Industrial Frame: Constructed on a heavy-duty 350 H-beam steel chassis to eliminate vibration during continuous high-speed operations.

Technical Specifications

Industrial Applications

The dual-profile sheets produced by this machine are ideal for diverse structural steel and building applications:

• Industrial & Commercial Roofing: Large-span factory workshops, warehouses, and logistics centers requiring durable wave-profile steel roofing.

• Residential & Architectural Roofing: Modern residential houses, villas, and agricultural sheds using colored wave-shaped or corrugated tiles.

• Wall Cladding & Fencing: Versatile corrugated sheets used for exterior wall panels and perimeter fencing.

Quality Assurance & Global Service

• Pre-Shipment Inspection: Every machine undergoes a 100% full-load trial run using the client's material specifications prior to packaging.

• Customization & Control: PLC multi-language touch screen system and hydraulic decoilers available upon request.

• After-Sales Support: Comprehensive technical guidance, site design layout support, and express spare parts replacement worldwide.
