Metal, steel, roof/wall/roof panels, metal sheets, fabrication, rolling forming machine

Metal, steel, roof/wall/roof panels, metal sheets, fabrication, rolling forming machine
Metal, steel, roof/wall/roof panels, metal sheets, fabrication, rolling forming machine Metal, steel, roof/wall/roof panels, metal sheets, fabrication, rolling forming machine Metal, steel, roof/wall/roof panels, metal sheets, fabrication, rolling forming machine Metal, steel, roof/wall/roof panels, metal sheets, fabrication, rolling forming machine Metal, steel, roof/wall/roof panels, metal sheets, fabrication, rolling forming machine

Large Image :  Metal, steel, roof/wall/roof panels, metal sheets, fabrication, rolling forming machine

Product Details:
Place of Origin: China
Brand Name: HC
Certification: CE
Model Number: 35-333-1000-1220
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: 40GP Container
Delivery Time: 30days
Payment Terms: L/C,T/T
Supply Ability: 60 Sets Per Month

Metal, steel, roof/wall/roof panels, metal sheets, fabrication, rolling forming machine

Description
Panel Thickness: 0.3-0.6mm Motor Power: 4+4KW
Machine Frame: 350 H Beam Cutting Method: Hydraulic Cutting
Decoiler Type: Hydraulic/manDecoileual R Roller Material: 45# Steel
Machine Type: Roll Forming Machine Production Capacity: 15-20m/min

Main Technical Parameters

Roller Stations

 17Stations

Roller & Shaft Material

45# Steel Quenching and Plating

Diameter of Shaft

Φ70mm

Cutter Material

CR12

Drive Type

Chain Drive

Speed

15-20m/min

Total Power

4+4KW

Voltage

380V 50Hz3Phases

Understanding the Forming System

Multi-Stage Roller Processing

The machine is equipped with 17 roller stations. During operation, metal material moves through each station and is progressively shaped into the required roofing profile.

Roller and Shaft Construction

The roller and shaft components use 45# steel with quenching and plating treatment. The specified shaft diameter is Φ70mm.

Cutting Technology

The cutting section uses CR12 material. It separates the formed metal sheet according to the required production length and machine settings.

Chain Drive Transmission

A chain drive system connects the machine's transmission components and delivers mechanical power to the forming section.

Production Operation

The machine follows a continuous processing sequence:

  1. Feed the metal material into the forming section.

  2. Guide the sheet through the 17 roller stations.

  3. Allow the rollers to progressively create the selected profile.

  4. Use the CR12 cutting component to separate the formed sheet.

  5. Collect the completed roofing panels for further handling.

The final sheet appearance depends on the roller profile and machine design.

Where This Machine Can Be Applied

With a suitable roller configuration, this equipment can be used in roofing sheet production for:

  • Industrial factories and workshops

  • Commercial buildings

  • Residential roofing projects

  • Warehouses and storage facilities

  • Agricultural construction

Before ordering, buyers should confirm the required roofing profile, raw material specifications, sheet dimensions, and cutting length.

Important Details for Machine Buyers

When comparing roofing sheet roll forming equipment, the number of roller stations, roller and shaft material, shaft diameter, cutting component, and transmission method are useful configuration details.

This model is specified with 17 stations, 45# steel rollers and shafts, a Φ70mm shaft, CR12 cutter, and chain drive. Buyers should also check whether the specified 380V, 50Hz, three-phase electrical supply matches their factory requirements.

Frequently Asked Questions

1. How many roller stations does this machine have?

It has 17 roller stations.

2. What is the shaft diameter?

The specified shaft diameter is Φ70mm.

3. What treatment is applied to the rollers and shafts?

They are made from 45# steel with quenching and plating.

4. What is the cutter material?

The cutter material is CR12.

5. What transmission system is used?

The machine uses chain drive transmission.

6. What is the production speed?

The specified speed is 15–20m/min.

7. What are the power and voltage specifications?

Total power is 4+4KW, with a voltage specification of 380V, 50Hz, 3 phases.

SEO Metadata

SEO Title: 17 Station Color Steel Roofing Sheet Roll Forming Machine

Meta Description: 17 station color steel roofing sheet roll forming machine featuring 45# steel rollers and shafts, Φ70mm shaft diameter, CR12 cutter, chain drive, and 15–20m/min speed.
