0.3-0.6mm Double Layer Roll Forming Machine For Roof Sheet

The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.

The control cabinet can be interconnected with other equipment, such as working with the uncoiler, hydraulic pump station, etc., to ensure the efficient and stable operation of the entire floor decking forming machine system, providing a strong guarantee for the production of high-quality floor decking.


Rollers are key components for processing and forming plates. In the leveling stage, the leveling rollers repeatedly roll the uneven plates by applying appropriate pressure to eliminate defects such as wavy and curved surfaces on the plate surface, so that the plate reaches the flatness required for subsequent forming.

Feeding Table & Pre-Cutter

During the conveying process, the feed table accurately controls the conveying speed and position of the metal sheet, and works closely with subsequent leveling devices, forming dies and other equipment

Shaft & Roller

The shaft provides a positioning reference for other components, ensuring the relative position accuracy between the components. For example, when installing transmission components such as gears and sprockets, the position of the shaft determines the installation position of these components, ensuring that the meshing and transmission relationship between them is accurate and the equipment runs smoothly.​
Pressing Section & Cutter

The tiles produced by the double-layer trapezoidal tile pressing machine need to be cut according to specific length specifications. The cutter can accurately cut the continuously formed tiles according to the preset length, ensuring that the length of each tile meets the construction requirements, ensuring the neatness and beauty of the tiles during laying, and also facilitating installation operations during the construction process.
