Roof Sheet Double Deck Steel Roll Forming Machine Chain Drive

Product Description

On large construction sites, double-layer tile pressing machines are directly placed in the temporary construction area of ​​the construction site. As the main body of the building gradually rises, the demand for roofing and wall materials is imminent. The tile pressing machine operates on-site and produces tiles immediately according to the actual needs of the building, reducing the loss and time cost during the transportation of tiles. Construction workers assist on the side and quickly transfer the newly produced tiles to the location where they need to be laid, which greatly improves the construction progress and ensures that the entire construction project can be completed on time.

Main Technical Parameters

Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
In the production process of floor decking, metal sheets are usually supplied in the form of coils. The primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.

Hydraulic Pump Station


When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.

Touch Screen Control Cabinet
