Product Description
On large construction sites, double-layer tile pressing machines are directly placed in the temporary construction area of the construction site. As the main body of the building gradually rises, the demand for roofing and wall materials is imminent. The tile pressing machine operates on-site and produces tiles immediately according to the actual needs of the building, reducing the loss and time cost during the transportation of tiles. Construction workers assist on the side and quickly transfer the newly produced tiles to the location where they need to be laid, which greatly improves the construction progress and ensures that the entire construction project can be completed on time.
Main Technical Parameters
| Material |
Type |
PPGI/GI |
| Thickness |
0.3-0.6mm |
| Width |
1000mm |
| Roller Stations |
10/13Stations |
| Roller & Shaft Material |
45# Steel Quenching and Plating |
| Diameter of Shaft |
Φ70mm |
| Cutter Material |
CR12 |
| Drive Type |
Chain Drive |
| Speed |
15m/min |
| Total Power |
5.5+5.5KW |
| Voltage |
380V 50Hz 3Phases |
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
In the production process of floor decking, metal sheets are usually supplied in the form of coils. The primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.
Hydraulic Pump Station
When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
The control cabinet can be interconnected with other equipment, such as working with the uncoiler, hydraulic pump station, etc., to ensure the efficient and stable operation of the entire floor decking forming machine system, providing a strong guarantee for the production of high-quality floor decking.
Feeding Table & Pre-Cutter
Conveyor rack: It is the basic support structure of the feed table, usually made of solid metal materials, such as steel plates, channel steels, etc. The conveyor rack is equipped with at least two sets of conveyor components for supporting and conveying the plates.
Shaft & Roller
The power of the power source such as the motor is transmitted to each working part, such as the rollers, gears, etc. The rotation of the shaft drives the rollers connected to it to rotate, so that the plate is gradually advanced between the rollers and the profiling process is completed, realizing the continuous production of glazed tiles.
Pressing Section & Cutter
The material of blade is CR12.
With high strength, better hardenability and good wear resistance.
The fast and accurate cutting function enables the production of glazed tiles to be continuous and automated, eliminating the need for tedious manual measurement and cutting operations, greatly improving production efficiency and reducing production time and labor costs.
