Roof Sheet Double Steel Deck Roll Forming Machine

Product Description
Industrial plants are usually large in scale and have a huge demand for roofing materials. With its efficient production capacity, the double-layer tile press can produce two different specifications of tiles at the same time, greatly shortening the production cycle and meeting the needs of rapid construction of industrial plants. Moreover, the tiles it produces are of reliable quality, with high dimensional accuracy after precise molding process, which can provide stable and durable roof covering for industrial plants and adapt to various climate and mechanical stresses that may be faced in industrial environment

Main Technical Parameters

Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm

It can adapt to various specifications of metal coils, including different widths, thicknesses and materials.

Hydraulic Pump Station

When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.

Touch Screen Control Cabinet

The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.

The control cabinet can also be interconnected with other equipment, such as working with the uncoiler, hydraulic pump station, etc., to ensure the efficient and stable operation of the entire floor decking forming machine system, providing a strong guarantee for the production of high-quality floor decking.



Feeding Table & Pre-Cutter

When there is a brief speed fluctuation in the upstream uncoiler or downstream forming equipment, the feed table can maintain the continuity of material transportation through its own buffer mechanism to avoid production stagnation or plate damage caused by speed differences.



Shaft & Roller



The shaft is the supporting base of the roller, which keeps the roller in the correct position and posture to ensure that it can stably press and shape the plate. Multiple groups of rollers are installed on the frame of the tile press through the shaft. The accuracy and strength of the shaft directly affect the concentricity and stability of the roller, and thus affect the forming quality of the glazed tile.

Pressing Section & Cutter

The material of blade is CR12.
With high strength, better hardenability and good wear resistance.



The reliability and durability of the cutter are also important factors affecting production stability. Carefully designed and manufactured cutters can maintain good cutting performance in long-term, high-intensity working environments, reducing the frequency of downtime and replacement due to cutter wear and damage, thereby reducing production costs and improving the company's production efficiency.
