Product Description
The double-layer tile pressing machine can produce two different specifications of tiles at the same time with its efficient production capacity, greatly shortening the production cycle and meeting the needs of rapid construction of industrial plants. Moreover, the tiles it produces are of reliable quality, with high dimensional accuracy after precise molding process, which can provide stable and durable roof covering for industrial plants and adapt to various climate and mechanical stresses that may be faced in industrial environments.
Main Technical Parameters
| Material |
Type |
PPGI/GI |
| Thickness |
0.3-0.6mm |
| Width |
915mm |
| Roller Stations |
12/13Stations |
| Roller & Shaft Material |
45# Steel Quenching and Plating |
| Diameter of Shaft |
Φ70mm |
| Cutter Material |
CR12 |
| Drive Type |
Chain Drive |
| Speed |
15m/min |
| Total Power |
5.5+5.5KW |
| Voltage |
380V 50Hz 3Phases |
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
Uncoilers play an indispensable role in the production process of tile presses. In the production process of tile presses, metal sheets are usually supplied in the form of coils, and the primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.
Hydraulic Pump Station
When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload
During the cutting process, the hydraulic pump station pushes the cutting tool to move quickly and powerfully, accurately cutting the formed floor decking according to the set length.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Users can store the production programs of floor decking boards of different specifications in the control cabinet. The next time they produce products of the same specifications, they can directly call them without resetting parameters, which greatly improves production efficiency.
Feeding Table & Pre-Cutter
The temporary loading platform after the metal coil is unwound ensures that the plates output from the uncoiler can be placed in an orderly manner to avoid plate accumulation and folding during the transition process.
Shaft & Roller
In the leveling stage, the leveling rollers apply appropriate pressure to repeatedly roll the uneven plates to eliminate the wavy and curved defects on the plate surface, so that the plate can reach the flatness required for subsequent forming. In the forming stage, a series of forming rollers of different shapes and specifications gradually cold-bend the plate in sequence.
Pressing Section & Cutter
The reliability and durability of the cutter are also important factors affecting production stability. Carefully designed and manufactured cutters can maintain good cutting performance in long-term, high-intensity working environments, reducing the frequency of downtime and replacement due to cutter wear and damage, thereby reducing production costs and improving the company's production efficiency.
