Efficient Double Deck Roll Forming Machine with 16 Stations and Chain Drive

Efficient Double Deck Roll Forming Machine with 16 Stations and Chain Drive
Efficient Double Deck Roll Forming Machine with 16 Stations and Chain Drive

Large Image :  Efficient Double Deck Roll Forming Machine with 16 Stations and Chain Drive

Product Details:
Place of Origin: China
Brand Name: HC
Certification: CE
Model Number: HC30-21-1220
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Main machine is nude,The workbench is packed with plastic stretch film
Delivery Time: 20-30 work days
Payment Terms: L/C, T/T
Supply Ability: 20set per month

Efficient Double Deck Roll Forming Machine with 16 Stations and Chain Drive

Description
Material Type: PPGI/GI Material Thickness: 0.3-0.6mm
Material Width: 1220mm Roller Stations: 16Stations
Roller & Shaft Material: 45# Steel Quenching And Plating Diameter Of Shaft: Φ70mm
Cutter Material: CR12 Drive Type: Chain Drive
Speed: 4m/min Total Power: 5.5+5.5KW
Voltage: 380v 50Hz 3phases
Highlight:

Chain Drive Roll Forming Machine

,

Efficient Double Deck Roll Forming Machine

,

16 Stations Roll Forming Machine

Product Description



In practical applications, double-layer trapezoidal tile pressing machines are widely used in roof and wall projects of various types of buildings such as industrial plants, warehouses, and residential buildings. The pressed trapezoidal tiles not only have beautiful appearance, but also have good waterproof and heat insulation properties, providing reliable protection for buildings.



Main Technical Parameters

Material Type PPGI/GI
Thickness 0.3-0.6mm
Width 1220mm
Roller Stations 12Stations
Roller & Shaft Material 45# Steel Quenching and Plating
Diameter of Shaft Φ70mm
Cutter Material CR12
Drive Type Chain Drive
Speed 15m/min
Total Power 5.5+5.5KW
Voltage 380V 50Hz 3Phases


Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting



Component & Technical Parameters

Double Deck Roll Forming Machine Manufacturers 0


This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
(adjustable according to demand.)
In order to avoid damage to the machine by impact when the machine is running, we have installed a brake device for you.

Hydraulic Pump Station
Double Deck Roll Forming Machine Manufacturers 1

The purpose of this pump station is to drive the cutter to start cutting works.
The hydraulic tank use 46# hydraulic oil.
Equipped with a cooling fan which can internal circulation coolingto ensure the oil pump station will not be affected by high oil temperature during working.
Solenoid valve brand: Huade

Touch Screen Control Cabinet

Double Deck Roll Forming Machine Manufacturers 2

The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Electrical Component Brand:
1. VFD: Delta
2. Circuit breakerDelixi
3. ContactorDelixi
4. RelayXinling
5. PLC: Delta
6. TransformerDelixi

Feeding Table & Pre-Cutter

Efficient Double Deck Roll Forming Machine with 16 Stations and Chain Drive 3

Guide the coil come into the correct position and going to the roll forming part.

Also including a Hand Pull Cutting Device, it is convenient to pre-cut the coil when want to changing color or thickness.



Shaft & Roller

Efficient Double Deck Roll Forming Machine with 16 Stations and Chain Drive 4

Material is 45# Steel Quenching and Plating.

The processed rollers are smooth, hard and will not rust.

Will not leave any scratches on the sheet when working.





Pressing Section & Cutter

Efficient Double Deck Roll Forming Machine with 16 Stations and Chain Drive 5

The material of blade is CR12.



After shaping, the metal is cut into individual slats of the required length. Precision cutting ensures uniformity in the final product.


Choosing a double-layer trapezoidal tile pressing machine means choosing an efficient and high-quality building board processing solution to safeguard your construction projects.
