Automatic Gutter Elbow Downspout Roll Forming Machine

Automatic Gutter Elbow Downspout Roll Forming Machine
Automatic Gutter Elbow Downspout Roll Forming Machine Automatic Gutter Elbow Downspout Roll Forming Machine Automatic Gutter Elbow Downspout Roll Forming Machine Automatic Gutter Elbow Downspout Roll Forming Machine Automatic Gutter Elbow Downspout Roll Forming Machine

Large Image :  Automatic Gutter Elbow Downspout Roll Forming Machine

Product Details:
Place of Origin: China
Brand Name: HC
Certification: CE
Model Number: HC100
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Main machine is nude,The workbench is packed with plastic stretch film
Delivery Time: 20-30 work days
Payment Terms: L/C, T/T
Supply Ability: 20set per month

Automatic Gutter Elbow Downspout Roll Forming Machine

Description
Material Type: GI/PPGI Material Thickness: 0.45mm-0.60mm
Material Width: 333mm Roller Station: 20Stations
Roller & Shaft Material: 45# Steel With Chrome Treatment Diameter Of Shaft: Φ70mm
Cutter Material: CR12 Cutting Method: Hydraulic Cutting
Drive Type: Chain Drive Maximum Forming Speed: 10-15m/min
Control System: PLC Control Total Power: 11+7.5KW
Voltage: 380V 50Hz 3Phases Seaming Method: The Seam To Be Folded Inwards.
Hree In One Machine: Roll Forming; Elbow; And End Shrink Function, All Three Function Are In One Machine.
Highlight:

Automatic Downspout Roll Forming Machine

,

Gutter Downspout Roll Forming Machine

,

Elbow Downspout Roll Forming Machine

Product Description



Material characteristics: It makes the steel building more integrated and the metal texture more expressive; there are a variety of color options to match the color of the building; there are a variety of elbows to match complex walls; the surface coating can withstand harsh weather and maintain its bright color



It has good strength and durability, can withstand greater pressure and impact; has good corrosion resistance and is suitable for various climatic conditions; has a long service life, which can reach decades or even hundreds of years.



Working Flow



Decoiling → Material Feeding → Roll Forming → Cutting → Collecting



Product Parameters



Main Technical Parameters

Material Type GI/PPGI
Thickness 0.45mm-0.60mm
Width 333mm
Roller Station 20Stations
Roller & Shaft Material 45# Steel with Chrome Treatment
Diameter of Shaft Φ70mm
Cutter Material CR12
Cutting Method Hydraulic Cutting
Drive Type Chain Drive
Maximum Forming Speed 10-15m/min
Control System PLC Control
Total Power 11+7.5KW
Voltage 380V 50Hz 3Phases
Seaming Method The seam to be folded inwards.
Three in One Machine roll forming; elbow; and end shrink function, all three function are in one machine.


Component Function



Manual Decoiler

Automatic Gutter Elbow Downspout Roll Forming Machine 0

This part is used to support Coil.

And make the coil in a rotary way.

Bearing capacity: 3T

Inner diameter: 470-530mm

(adjustable according to demand)



Shaft & Roller

Automatic Gutter Elbow Downspout Roll Forming Machine 1

Material is 45# Steel with Chrome Treatment.

The processed rollers are smooth, hard and will not rust.

Will not leave any scratches on the sheet when working.



Hydraulic Pump Station



Automatic Gutter Elbow Downspout Roll Forming Machine 2

It use 46# hydraulic oil.

The purpose of this pumping station is to control the cutter to start the cutting work.







Automatic Gutter Elbow Downspout Roll Forming Machine 3

The control cabinet has two modes, automatic and manual.

The unit length of the targeted sheet can be set in the control cabinet.

The system is simple and easy to operate.

Cutter

Automatic Gutter Elbow Downspout Roll Forming Machine 4

The material of blade is CR12.

With high strength, better hardenability and good wear resistance.

End Shrink Device

Automatic Gutter Elbow Downspout Roll Forming Machine 5

Shrinking method: Four points shrink inward.

In order to put one tube into another.



Equipment advantages

High production efficiency: It can realize automated continuous production. For example, Cold-bent's color steel round downpipe forming machine has stable operation and can quickly process raw materials into finished products, effectively improving production efficiency.

Good product quality: It adopts high-precision control system and advanced forming technology to ensure the size and shape accuracy of downpipes, so that the finished products have uniform specifications and correct shapes. For example, Hongan Machinery's forming machine has no burrs on the cut and good surface quality.

Low production cost: The downpipe forming machine can accurately control the amount of raw materials, reduce waste, and reduce raw material costs.

Moreover, the equipment has a high degree of automation, which reduces manual operation and labor costs.

Wide range of applications: By replacing different molds or adjusting equipment parameters, it can produce downpipes of various specifications, shapes and materials to meet different architectural styles and drainage needs, such as metal, plastic materials, round, square shapes, etc.

Easy operation: The equipment's automated control system and user-friendly operation interface reduce the professional requirements for operators. After simple training, they can be proficient in operation, reducing the cost and time of personnel training.

Strong safety performance: Equipped with complete safety protection devices, such as emergency stop buttons, guardrails, photoelectric sensors, etc., it effectively prevents operators from accidents and improves the safety of the production process.
