|Usage:||Stud And Track||Type:||Cold Roll Forming Machine|
|Power:||4.5+5+2.3kw||Thickness Of The Plate:||0.3-0.6mm|
0.6mm light gauge steel roll forming machine,
delta light gauge steel roll forming machine,
fly shear light gauge steel machine
|1. The Product Description of cee purlins|
(1). Brief Introduction
The purlin made by C Purlin Roof Steel Profile Roll Forming Machine is widely used in the main body stress
structure of the large and medium-size construction, such as the plant, the warehouse, locomotive shed,
hangar, exhibition building. it is known as economic and high efficient building material.
The steel C purlin has following features:
a. Light weight, low cost;
b. Easy to operate: the purlin can be formed and punched according to your actural need;
and it can be installed directly.
(2). Working Flow of Roll Forming Machine
Coil decoiling-Coil feeding-Leveling-Roll forming-Punching(optional)-Length measuring-Sheet
|Suitable Material||Hot rolled strip steel, Q235 or equivalent|
|Material Thickness||0.6 mm|
|Dimension||About 4.0*1.2*1.75m(L*W*H) , as per the drawing|
|Working Space||About 10.0*2.7m(L*W)|
You can set the length according to your need.
It is controlled by PLC
which can ensure the accuracy of ±1mm.
Automatically stop and cutting when it comes to the set
B. Components Details
|Roller Material||High grade 45# steel. Hard chrome plating, 0.05mm.|
|Main Frame||400# steel. More stable and no shaking.|
16mm. We use thicker plates to ensure stability
of our products.
|Forming Steps||11-16, according to the drawing.|
|Shaft Material||Φ70 mm, high grade 45# steel.|
Treating process: tempering- finish turning,
high rigidity, hard to deform.
|Cr12, hardness HRC60-62.|
|Treating process: heat treatment- plane abrasion- wire electrode cutting.|
C. Electric Components
|Suitable Power||380V, 50 Hz, 3 phase or according to your need.|
|Screen||7 inch touch screen, easy to operate.|
Well-adapted to various conditions, such as moisture,
Delta VFD-M. It has the advantage of slowing down before cutting,
to ensure the length accuracy (±1mm,
far better than industrial standard ±3mm).
|Omron, made in Japan.|
|It features with high accuracy and stability.|
1. Can you make the machine according to my design or photo type?
A: Yes. We have an experienced team to work out the most suitable design and production plan
for the machine.
2: How can we be assured that you will deliver us quality machine with spare parts?
A:1. Customers to send the technical people to our factory for checking the quality.
2.We can send the technicians to the buyer`s factory for the installation of the machine.
3.What policy of your garentee?
A: Within the One-YEARS period, we could supply you the replacement parts free of charge
for any damaged parts caused by quality problems after two years,you need to buy by factory cost.
