Roof Wall Panel Double Deck Roll Forming Machine

Product Description

Equipped with advanced CNC operating system, the operation interface is simple and intuitive, and workers can easily achieve precise control of the tile press. Parameters such as plate thickness, corrugation spacing, and forming speed can be flexibly adjusted, and the length accuracy is controlled within ±1mm, which greatly improves the flexibility of production and the stability of product quality.
The mold is made of special alloy steel, and after multiple fine processing and surface hardening treatment, the wear resistance is improved by more than 50% compared with ordinary molds, which effectively reduces the frequency of mold replacement and extends the service life of the equipment, saving a lot of mold replacement costs and maintenance time for enterprises

Main Technical Parameters

Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm

Uncoilers play an indispensable role in the production process of tile presses. In the production process of tile presses, metal sheets are usually supplied in the form of coils, and the primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.



Hydraulic Pump Station

When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.



Touch Screen Control Cabinet

The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.

Feeding Table & Pre-Cutter

The feed table is generally equipped with positioning devices, such as baffles or positioning pins, which are used to accurately position the plates to ensure that the plates are in the correct position and direction when entering the tile press

Pressing Section & Cutter

Fast and efficient cutting action can reduce the production time of a single tile, thereby improving the production efficiency of the entire tile press. The cutting speed of the cutter can usually be adjusted according to the operating speed of the tile press and the material of the board to achieve the best production rhythm.
