Product Details:
|
| Material Type: | PPGI/GI | Material Thickness: | 0.3-0.6mm |
|---|---|---|---|
| Material Width: | 1220mm | Roller Stations: | 12/17 Stations |
| Roller & Shaft Material: | 45# Steel Quenching And Plating | Diameter Of Shaft: | Φ70mm |
| Cutter Material: | CR12 | Drive Type: | Chain Drive |
| Speed: | 15m/min | Total Power: | 5.5+5.5KW |
| Voltage: | 380v 50Hz 3phases | ||
| Highlight: | Tile Roof Roll Forming Machine |
||
Product Description
The structural design of the double-layer trapezoidal tile press is relatively reasonable, and the key components are made of high-quality materials with high wear resistance and reliability. Under normal use, the failure rate of the equipment is low and the maintenance work is relatively simple. Regular routine maintenance such as cleaning, lubrication and inspection of the equipment can ensure the normal operation of the equipment and reduce maintenance costs and downtime.
Main Technical Parameters
| Material | Type | PPGI/GI |
| Thickness | 0.3-0.6mm | |
| Width | 1220mm | |
| Roller Stations | 12/17Stations | |
| Roller & Shaft Material | 45# Steel Quenching and Plating | |
| Diameter of Shaft | Φ70mm | |
| Cutter Material | CR12 | |
| Drive Type | Chain Drive | |
| Speed | 15m/min | |
| Total Power | 5.5+5.5KW | |
| Voltage | 380V 50Hz 3Phases | |
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
Uncoilers play an indispensable role in the production process of tile presses. In the production process of tile presses, metal sheets are usually supplied in the form of coils, and the primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.
Hydraulic Pump Station
During the tile pressing process, the hydraulic pump station can control the action of the feed hydraulic cylinder and the pressing hydraulic cylinder to match the feed speed of the plate with the pressing speed, thus ensuring the continuity and stability of the tile pressing process.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Feeding Table & Pre-Cutter
Guide and position the feeding direction of the sheet to ensure that the sheet can enter the forming rollers of the tile press accurately and ensure that the tile press rolls the sheet evenly and accurately, thereby producing double-layer trapezoidal corrugated sheets that meet specifications and quality requirements.
Shaft & Roller
High-precision axes can make the movement of components such as rollers more stable and accurate, thereby ensuring that the pressed tiles have high dimensional accuracy, regular shapes, uniform corrugations, and reduce quality defects of tiles.
Pressing Section & Cutter
Through precise cutting, the dimensional accuracy and quality stability of color steel tiles can be effectively controlled. The length and shape of each tile can be accurately controlled, so that the tiles can better cooperate with each other after installation, ensuring the sealing and waterproof properties of the roof or wall, and improving the overall quality of the building.
