Product Details:
|
| Material Type: | PPGI/GI | Material Thickness: | 0.3-0.6mm |
|---|---|---|---|
| Material Width: | 1250mm | Roller Stations: | 15Stations |
| Roller & Shaft Material: | 45# Steel Quenching And Plating | Diameter Of Shaft: | Φ70mm |
| Cutter Material: | CR12 | Drive Type: | Chain Drive |
| Speed: | 15m/min | Total Power: | 5.5+5.5KW |
| Voltage: | 380v 50Hz 3phases | ||
| Highlight: | Ibr Roll Forming Machine |
||
Product Description
The structural design of the double-layer trapezoidal tile press is relatively reasonable, and the key components are made of high-quality materials with high wear resistance and reliability. Under normal use, the failure rate of the equipment is low and the maintenance work is relatively simple. Regular cleaning, lubrication and inspection of the equipment can ensure the normal operation of the equipment and reduce maintenance costs and downtime.
Main Technical Parameters
| Material | Type | PPGI/GI |
| Thickness | 0.3-0.6mm | |
| Width | 1250mm | |
| Roller Stations | 15Stations | |
| Roller & Shaft Material | 45# Steel Quenching and Plating | |
| Diameter of Shaft | Φ70mm | |
| Cutter Material | CR12 | |
| Drive Type | Chain Drive | |
| Speed | 15m/min | |
| Total Power | 5.5+5.5KW | |
| Voltage | 380V 50Hz 3Phases | |
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
In the production process of glazed tiles, metal sheets are usually supplied in the form of coils. The primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.
Hydraulic Pump Station
When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Feeding Table & Pre-Cutter
The surface of the feed table is usually made of smooth, wear-resistant materials or coatings that will not scratch the plate, avoiding scratches, abrasion and other damage to the plate surface during plate transportation and loading, protecting the surface quality and coating integrity of the plate, especially for some plates with special surface treatment or high appearance requirements.
Shaft & Roller
During the tile pressing process, the contact between the wheel and the plate can play a certain buffering role, reducing the impact force of the tile press on the plate at the moment of pressing, avoiding damage to the plate due to excessive force, and at the same time reducing the vibration and noise of the equipment and protecting other parts of the equipment.
Pressing Section & Cutter
Through precise cutting, the dimensional accuracy and quality stability of color steel tiles can be effectively controlled. The length and shape of each tile can be accurately controlled, so that the tiles can better cooperate with each other after installation, ensuring the sealing and waterproof properties of the roof or wall, and improving the overall quality of the building.
