PPGI / GI Steel Profile Double Deck Roll Forming Machine

Product Description

Double-layer trapezoidal corrugated board can reduce the use of raw materials such as steel through reasonable design while ensuring structural strength and performance. Compared with traditional building boards, double-layer trapezoidal corrugated board is lighter but stronger, which reduces construction costs to a certain extent and improves economic benefits.

Main Technical Parameters

Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm

The core function of the uncoiler is to unwind and unwind the rolled metal sheets (such as color-coated steel sheets, galvanized sheets, etc.) so that the sheets can continuously and smoothly enter the subsequent processing links of the double-layer tile pressing machine, providing the tile pressing machine with a steady supply of raw materials and ensuring the continuity of the tile pressing production process.

Hydraulic Pump Station


The hydraulic pump station is one of the power sources of the double-layer tile press. It drives the oil pump through an electric motor to convert mechanical energy into hydraulic energy, providing power for the various hydraulic actuators of the tile press (such as hydraulic cylinders, hydraulic motors, etc.), so that the tile press's pressing, cutting and other actions can be completed smoothly.

Touch Screen Control Cabinet
