Product Details:
|
| Material Type: | PPGI/GI | Material Thickness: | 0.3-0.6mm |
|---|---|---|---|
| Material Width: | 1250mm | Roller Stations: | 12 Stations |
| Roller & Shaft Material: | 45# Steel Quenching And Plating | Diameter Of Shaft: | Φ70mm |
| Cutter Material: | CR12 | Drive Type: | Chain Drive |
| Speed: | 4m/min | Total Power: | 5.5+5.5KW |
| Voltage: | 380v 50Hz 3phases | ||
| Highlight: | 1250mm Glazed Tile Roll Forming Machine,1250mm Roll Forming Machine |
||
Product Description
The glazed tile pressing machine adopts an automated production process and has a fast operating speed, and can produce a large number of glazed tiles in a short time. Compared with traditional manual production or other relatively backward production methods, it greatly improves production efficiency and can meet the needs of large-scale construction projects.
Main Technical Parameters
| Material | Type | PPGI/GI |
| Thickness | 0.3-0.6mm | |
| Width | 1250mm | |
| Roller Stations | 12Stations | |
| Roller & Shaft Material | 45# Steel Quenching and Plating | |
| Diameter of Shaft | Φ70mm | |
| Cutter Material | CR12 | |
| Drive Type | Chain Drive | |
| Speed | 4m/min | |
| Total Power | 5.5+5.5KW | |
| Voltage | 380V 50Hz 3Phases | |
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
In the production process of glazed tiles, metal sheets are usually supplied in the form of coils. The primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.
Hydraulic Pump Station
When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Feeding Table & Pre-Cutter
During the sheet feeding process, the feed table can play a certain buffering role. When the sheet is transferred from the external loading device to the feed table, the conveying device of the feed table can receive the sheet at a relatively slow speed, reducing the impact force of the sheet during the transfer process and avoiding damage to the feed port or internal components of the tile press.
Shaft & Roller
The shaft is the supporting base of the roller, which keeps the roller in the correct position and posture to ensure that it can stably press and shape the plate. Multiple groups of rollers are installed on the frame of the tile press through the shaft. The accuracy and strength of the shaft directly affect the concentricity and stability of the roller, and thus affect the forming quality of the glazed tile.
Pressing Section & Cutter
The material of blade is CR12.
With high strength, better hardenability and good wear resistance.
The maintenance of the equipment is relatively simple. The design of each component is convenient for disassembly and repair, and the spare parts of the equipment are easy to obtain on the market, which reduces the maintenance cost and difficulty of the equipment.
