Corrugated Roof Sheet Making Maquina Para Hacer Teja Floor Deck Roll Forming Machine

Product Description

It can process various types of metal plates, such as galvanized steel plates, color-coated steel plates, etc., to meet the performance and appearance requirements of floor decking in different construction projects. At the same time, according to different plate materials and thicknesses, the equipment can automatically adjust the forming parameters to ensure good forming effects.

Main Technical Parameters

Working Flow

Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

his part is used to support Coil.

And make the coil in a rotary way.

Bearing capacity: 5T

Inner diameter: 470-530mm

(adjustable according to demand.)

In order to avoid damage to the machine by impact when the machine is running, we have installed a brake device for you.

Hydraulic Pump Station

The purpose of this pump station is to drive the cutter to start cutting works.

The hydraulic tank use 46# hydraulic oil.

Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.

Touch Screen Control Cabinet

The control cabinet has two modes, automatic and manual modes.

The unit length of the targeted sheet and quantity can be set in the touchscreen.

The system is simple and easy to operate.

Output Table

This part is used to collect the formed products.

The bracket is equipped with rollers to facilitate the product forwarding without being scratched.

Feeding Table

Guide the coil come into the correct position and passed to the roll forming machine.

Shaft & Roller

Material is 45# Steel Quenching and Plating.

The processed rollers are smooth, hard and will not rust.

Will not leave any scratches on the sheet when working.

Cutter

The material of blade is CR12.

With high strength, better hardenability and good wear resistance.

Through the operation panel, operations such as starting, stopping, and setting parameters of the equipment can be easily achieved, reducing the requirements for the professional skills of the operator.
