Customizable Double Deck Roll Forming Machinery For Steel

The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Electrical Component Brand:
1. VFD: Delta
2. Circuit breaker: Delixi
3. Contactor: Delixi
4. Relay: Xinling
5. PLC: Delta
6. Transformer: Delixi

Feeding Table & Pre-Cutter

Guide the coil come into the correct position and going to the roll forming part.

Also including a Hand Pull Cutting Device, it is convenient to pre-cut the coil when want to changing color or thickness.

Shaft & Roller

Material is 45# Steel Quenching and Plating.

The processed rollers are smooth, hard and will not rust.

Will not leave any scratches on the sheet when working.

Pressing Section & Cutter

The material of blade is CR12.

After shaping, the metal is cut into individual slats of the required length. Precision cutting ensures uniformity in the final product.

While the first layer is being formed, another similar forming system is forming the second layer of sheet material. This process is similar to the first layer, but due to the double-layer design, precise synchronous control is required. High-precision transmission devices and control systems are usually used to ensure the synchronization of the two-layer forming. For example, the movement of the two-layer forming rollers is coordinated through a synchronous shaft or electronic sensor so that they complete the same forming steps in the same time, thereby producing two trapezoidal tiles with the same or different specifications.
