Professional PPGI / GI Material Double Deck Roll Forming Machine Manufacturers

Large Image : Professional PPGI / GI Material Double Deck Roll Forming Machine Manufacturers

Product Details:

Place of Origin:	China
Brand Name:	HC
Certification:	CE
Model Number:	HC24-44-1250

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	Main machine is nude，The workbench is packed with plastic stretch film
Delivery Time:	20-30 work days
Payment Terms:	L/C, T/T
Supply Ability:	20set per month

Contact Now

Professional PPGI / GI Material Double Deck Roll Forming Machine Manufacturers

Description

Material Type:	PPGI/GI	Material Thickness:	0.3-0.6mm
Material Width:	1250mm	Roller Stations:	12/17 Stations
Roller & Shaft Material:	45# Steel Quenching And Plating	Diameter Of Shaft:	Φ70mm
Cutter Material:	CR12	Drive Type:	Chain Drive
Speed:	15m/min	Total Power:	5.5+5.5KW
Voltage:	380v 50Hz 3phases
Highlight:	Professional Double Deck Roll Forming Machine , Double Deck Roll Forming Machine Manufacturers , PPGI / GI double layer forming machine

Product Description
Commercial buildings such as shopping malls and hotels have high requirements for the appearance of buildings. The tiles produced by the double-layer trapezoidal tile pressing machine can be produced in different colors and specifications according to the requirements of the architectural design, which can be used to create distinctive commercial building roofs to attract customers' attention. Moreover, its waterproof performance can also effectively protect the space inside the commercial building.

Main Technical Parameters

Material	Type	PPGI/GI
	Thickness	0.3-0.6mm
	Width	1250mm
Roller Stations		12/17Stations
Roller & Shaft Material		45# Steel Quenching and Plating
Diameter of Shaft		Φ70mm
Cutter Material		CR12
Drive Type		Chain Drive
Speed		15m/min
Total Power		5.5+5.5KW
Voltage		380V 50Hz 3Phases

Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
(adjustable according to demand.)
In order to avoid damage to the machine by impact when the machine is running, we have installed a brake device for you.

Hydraulic Pump Station

The purpose of this pump station is to drive the cutter to start cutting works.
The hydraulic tank use 46# hydraulic oil.
Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.
Solenoid valve brand: Huade

Touch Screen Control Cabinet

The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Electrical Component Brand:
1. VFD: Delta
2. Circuit breaker: Delixi
3. Contactor: Delixi
4. Relay: Xinling
5. PLC: Delta
6. Transformer: Delixi

Feeding Table & Pre-Cutter

Guide the coil come into the correct position and going to the roll forming part.

Also including a Hand Pull Cutting Device, it is convenient to pre-cut the coil when want to changing color or thickness.

Shaft & Roller

Material is 45# Steel Quenching and Plating.

The processed rollers are smooth, hard and will not rust.

Will not leave any scratches on the sheet when working.

Pressing Section & Cutter

The material of blade is CR12.

After shaping, the metal is cut into individual slats of the required length. Precision cutting ensures uniformity in the final product.

In terms of building exterior wall decoration, the tiles produced by the double-layer trapezoidal tile pressing machine can be used as a new type of decorative material. When installed on the wall, it can form a unique texture and shape, increasing the layering and three-dimensional sense of the building exterior wall. Compared with traditional exterior wall decoration materials, this type of tile has better weather resistance and durability, and can maintain a good appearance for a long time.
