PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage

1
MOQ
PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage
Features Gallery Product Description Request A Quote
Features
Specifications
Material Type: PPGI/GI
Material Thickness: 0.3-0.6mm
Material Width: 1250mm
Roller Stations: 12/16Stations
Roller & Shaft Material: 45# Steel Quenching And Plating
Diameter Of Shaft: Φ70mm
Cutter Material: CR12
Drive Type: Chain Drive
Voltage: 380v 50Hz 3phases
Highlight:

PPGI Double Deck Roll Forming Machine

,

380v Double Deck Roll Forming Machine

,

GI double layer forming machine
Basic Infomation
Place of Origin: China
Brand Name: HC
Certification: CE
Model Number: HC12-16-1000
Payment & Shipping Terms
Packaging Details: Main machine is nude，The workbench is packed with plastic stretch film
Delivery Time: 20-30 work days
Payment Terms: L/C, T/T
Supply Ability: 20set per month
Product Description

Product Description



A dual-purpose machine can produce two types of color steel tiles at the same time. Compared with the traditional single-layer tile press, the output is greatly increased, the production efficiency is significantly improved, and the production cycle is shortened.



Main Technical Parameters

Material Type PPGI/GI
Thickness 0.3-0.6mm
Width 1250mm
Roller Stations 12/16Stations
Roller & Shaft Material 45# Steel Quenching and Plating
Diameter of Shaft Φ70mm
Cutter Material CR12
Drive Type Chain Drive
Speed 15m/min
Total Power 5.5+5.5KW
Voltage 380V 50Hz 3Phases


Working Flow

Decoiling → Material Feeding → Roll Forming → Cutting → Collecting



Component & Technical Parameters

PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage 0

Decoiler: This component unwinds the metal coil, which is typically made of steel or aluminum, and feeds it into the machine.



Hydraulic Pump Station

PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage 1



The purpose of this pump station is to drive the cutter to start cutting works.

The hydraulic tank use 46# hydraulic oil.

Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.

Solenoid valve brand: Huade



Touch Screen Control Cabinet

PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage 2

The control cabinet has two modes, automatic and manual modes.

The unit length of the targeted sheet and quantity can be set in the touchscreen.

The system is simple and easy to operate.

Electrical Component Brand:

1. VFD: Delta

2. Circuit breaker: Delixi

3. Contactor: Delixi

4. Relay: Xinling

5. PLC: Delta

6. Transformer: Delixi



Shaft & Roller



PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage 3



Roll Forming Machine: The heart of the system, this machine shapes the metal into the desired profile or slat design. Roll forming involves passing the metal through a series of rollers, each with a specific contour to gradually shape the material.



Pressing Section & Cutter


PPGI / GI Material Type Double Deck Roll Forming Machine with 380v 50Hz 3 phases Voltage 4

The material of blade is CR12.

With high strength, better hardenability and good wear resistance.



Before buying, consult different suppliers for prices, and be aware that equipment with too low a price may have quality problems. Compare the prices of double-layer tile pressing machines of different brands and configurations, and make a choice based on your budget and requirements for equipment performance.​



Why Book With Us?

1.We have 20 years of experience in production and sales of tile presses
2.We know the commonly used tile types in each region and can recommend them to customers
3.We have an excellent design and production team that can design and manufacture according to customer needs.
4.We have our own company and welcome customers at any time
5.We can help you contact the shipping company and we can also deliver to your door if you need.
