Product Details:
|
| Material Type: | PPGI/GI | Material Thickness: | 0.3-0.6mm |
|---|---|---|---|
| MaterialWidth: | 1200/1220mm | Roller Stations: | 12+15Stations |
| Roller & Shaft Material: | 45# Steel Quenching And Plating | Diameter Of Shaft: | Φ70mm |
| Cutter Material: | CR12 | Drive Type: | Chain Drive |
| Speed: | 15m/min | Total Power: | 5.5+5.5KW |
| Voltage: | 380V 50Hz 3Phases | ||
| Highlight: | Trapezoidal Roll Forming Machine,Metal Tile Roll Forming Machine,Double Layer Tile Roll Forming Machine |
||
Product Description
Trapezoidal double-layer tile forming machine is a mechanical equipment specially used for producing trapezoidal double-layer tiles. Its main function is to process metal plates (such as color steel plates, aluminum plates, etc.) through a series of forming rollers, and gradually process the plates into a tile shape with a trapezoidal cross-section and a double-layer structure. This kind of tile is usually used for decoration and protection of building roofs and walls.
Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Main Technical Parameters
| Material | Type | PPGI/GI |
| Thickness | 0.3-0.6mm | |
| Width | 1200/1220mm | |
| Roller Stations | 12+15Stations | |
| Roller & Shaft Material | 45# Steel Quenching and Plating | |
| Diameter of Shaft | Φ70mm | |
| Cutter Material | CR12 | |
| Drive Type | Chain Drive | |
| Speed | 15m/min | |
| Total Power | 5.5+5.5KW | |
| Voltage | 380V 50Hz 3Phases | |
Component & Technical Parameters
This part is used to support Coil.And make the coil in a rotary way.
Bearing capacity: 3TInner diameter: 470-530mm.(adjustable according to demand)
Shaft & Roller
Roll Forming Machine: The heart of the system, this machine shapes the metal into the desired profile or slat design. Roll forming involves passing the metal through a series of rollers, each with a specific profile, to gradually shape the material.
Cutter
The material of blade is CR12.
With high strength, better hardenability and good wear resistance.
Hydraulic Pump Station
The purpose of this pump station is to drive the cutter to start cutting works.
The hydraulic tank use 46# hydraulic oil.
Equipped with a cooling fan which can internal circulation cooling, to ensure the oil pump station will not be affected by high oil temperature during working.
Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
