Good Quality Door Frame Roll Forming Machine Provider From China

Customer Reviews
Machine easy to use. The boss is very nice.

—— Mr.Angolon From Europe

This is a good manufacturer, a good English communicater, and I like your machines. It is good quality, and pretty!

—— Mr.Mark From Africa

Nice supplier! I like your swift delivery and quick production cycle, will keep in touch with you guys.

—— Mr.Jack From America

I'm Online Chat Now

Good Quality Door Frame Roll Forming Machine Provider From China

Good Quality Door Frame Roll Forming Machine Provider From China
Good Quality Door Frame Roll Forming Machine Provider From China

Large Image :  Good Quality Door Frame Roll Forming Machine Provider From China

Product Details:
Place of Origin: CHINA
Brand Name: Huachen
Certification: CE
Model Number: HC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation between the two parties
Packaging Details: non
Delivery Time: 45days
Payment Terms: T/T
Supply Ability: 20set per month

Good Quality Door Frame Roll Forming Machine Provider From China

Description
Material: PPIG IG Aluminum Thickness: 1.6-2mm
Speed: 10m/min Color: Blue
Width: 1220mm Roller Stations: 18stations
Roller Shaft Material: 45#steel With Chrome Treatment Diameter Of Shaft: ∅70mm
Cutter Material: CR12 Total Power: 5.5+5.5+5.5Kw
Voltage: 220v 60Hz 3phases

Product Description

Good Quality Door Frame Roll Forming Machine Provider From China

Door Frame Roll Forming Machine: An Introduction
A door frame roll forming machine is a specialized piece of equipment used in the manufacturing of door frames from metal sheets, typically steel or aluminum. This machine automates the process of shaping metal into consistent and precise profiles that are essential for constructing durable door frames.

Key Features
High Efficiency: The machine can produce large quantities of door frames in a short period, increasing productivity.
Precision Engineering: It ensures that each door frame is manufactured to exact specifications, minimizing waste and errors.
Versatility: Capable of producing various shapes and sizes of door frames, accommodating different design requirements.
Automated Process: With PLC (Programmable Logic Controller) systems, the process is automated, allowing for easy operation and quality control.
Durable Construction: Built to withstand continuous operation, these machines often feature robust materials and components.
Working Principle
Feeding: Metal coils are fed into the machine.
Roll Forming: The metal passes through a series of rollers that gradually shape it into the desired frame profile.
Cutting: Once the frame reaches the required length, it is cut to size using either a shear or a cutoff saw.
Finishing: The frames may undergo additional processes such as punching holes for hinges or applying surface treatments.



Good Quality Door Frame Roll Forming Machine Provider From China 0
Finished Products Showing

Good Quality Door Frame Roll Forming Machine Provider From China 1

 Product Parameter

Material Type PPGI/GI
  Thickness 1.6-2mm
Roller Station 18Stations
Roller & Shaft Material 45# Steel Quenching and Plating
Diameter of Shaft Φ80mm
Cutter Material CR12
Drive Type Chain Drive
Maximum Forming Speed 10m/min
Control System PLC Control
Total Power 5.5+5.5+5.5KW
Voltage 415V 50Hz 3Phases

Good Quality Door Frame Roll Forming Machine Provider From China 2
Good Quality Door Frame Roll Forming Machine Provider From China 3
Good Quality Door Frame Roll Forming Machine Provider From China 4
Good Quality Door Frame Roll Forming Machine Provider From China 5
Workshop Scene
Good Quality Door Frame Roll Forming Machine Provider From China 6
Good Quality Door Frame Roll Forming Machine Provider From China 7
Good Quality Door Frame Roll Forming Machine Provider From China 8
Good Quality Door Frame Roll Forming Machine Provider From China 9
Good Quality Door Frame Roll Forming Machine Provider From China 10
We Can Also Make The Following Machines
NO. NAME
1 Single layer roll forming machine
2 Duoble layer roll forming machine
3 Trapezoidal roll forming machine
4 Glazed tile roll forming machine
5 Currugated roll forming machine
6 Floor deck roll forming machine
7 Roll shutter door forming machine
8 C/Z/Uprofile steel forming machine
9 Ridge cap roll forming machine
10 Downspout forming machine
11 Keel roll forming machine
12 Heat retaining sandwich panel
13 Highway guardrail roll forming machine
14 Carrige board roll forming machine
15 High-frequency pipe welder
16 Hydraulic full-automatic decoiler and accessory equipments
17 Color steel roll forming machine
18 Joint-hidden type forming machine
19 Colorfull stone-coated steel
20 No-girder arched roll forming machine
21 Standing seam arching machine
22 Hydraulic crimping curving machine
23 Steel coil slitting roll forming machine
24 Windshield dust-controlling board producing line
25 Some others can be made on request



Good Quality Door Frame Roll Forming Machine Provider From China 11

Good Quality Door Frame Roll Forming Machine Provider From China 12

Good Quality Door Frame Roll Forming Machine Provider From China 13

Good Quality Door Frame Roll Forming Machine Provider From China 14

Good Quality Door Frame Roll Forming Machine Provider From China 15
Why Book With Us?
1.We have 20 years of experience in production and sales of tile presses
2.We know the commonly used tile types in each region and can recommend them to customers
3.We have an excellent design and production team that can design and manufacture according to customer needs.
4.We have our own company and welcome customers at any time
5.We can help you contact the shipping company and we can also deliver to your door if you need.
