14-18 Station Galvanized Steel CZ Purlin Roll Forming Machine With Precise Cutting Control

Product Description:

An automatic CZ purlin roll forming machine is an advanced device tailored for the creation of CZ-shaped purlins, which are critical structural supports utilized chiefly within the building sector for roofs and walls.

Adhering to the core principles of roll forming, this machine is uniquely engineered to fabricate C and Z purlins with exceptional precision and efficiency. Notable features and elements include:

• Uncoiler: Maintains the steel coil and directs it into the apparatus.
• Leveling and Feeding System: Ensures the steel strip is straight and precisely fed into the forming section.
• Roll Forming Section: Constituted by a succession of roll stands with rollers that incrementally forge the steel strip into a CZ profile. Adjustable stands allow for the creation of varying purlin sizes.
• Punching/Cutting System: A machine module that can punch the purlins with holes or slots, complemented by a system to trim purlins to required lengths.
• Hydraulic or Servo-Driven System: Empowers the forming process with requisite energy and precision in roll driving and speed control.
• Control System: Boasts a computerized panel permitting operators to stipulate dimensions, quantity, and profile criteria. It also maintains and tweaks operations for steadfast accuracy.

The deployment of an automatic CZ purlin roll forming machine ensures enhanced productivity and efficiency through its capability to continuously and autonomously churn out purlins. Adaptable to a variety of steel thicknesses and purlin dimensions, these machines significantly reduce manual labor and are indispensable for the swift manufacturing of CZ purlins in large-scale construction endeavours.

Features:

• Product Name: CZ Purlin Roll Forming Machine
• Cutting Tolerance: ±1mm
• Drive Type: Chain Drive
• Material Width: Customizable Based On Need
• Material Type: Galvanized Steel
• Automatic CZ Purlin Roll Forming Machine
• Automatic CZ Purlin Roll Forming Machine
• Automatic CZ Purlin Roll Forming Machine

Technical Parameters:

Applications:

Within the construction realm, CZ purlins are integral to the structural framework of edifices. Excelling beyond customary building components like wooden beams or steel, they are chiefly employed in both roof and wall assemblies. The ensuing segments delineate their predominant uses:

As foundational support in roofing, CZ purlins underpin roof coverings - namely metallic panels or insulated sandwich panels - ensuring the equitable dispersion of loads throughout the building's skeleton.

CZ purlins perform similarly in wall constructions, bolstering the cladding materials. This is fundamental in preserving wall stability and robustness, specifically within sprawling industrial or mercantile structures.

Frequently, CZ purlins are cast in a supporting role to primary structure constituents like steel pillars and rafters. Their utility lies in bridging these main elements, thus enhancing the structural fortitude of the edifice.

In the creation of intermediate mezzanine levels, which are supplementary floors slotted between the primary ones, CZ purlins provide an enduring and enduring substructure.

Due to their light nature, straightforward assembly, and cost efficiency, CZ purlins are the go-to for erecting industrial sheds and storage warehouses.

In the sector of agriculture, CZ purlins are incorporated into barns, storage sections, and shelters for animals, imparting a sound and reliable framework suited for agrarian construction needs.

CZ purlins are celebrated for their adaptability, allowing them to be tailor-made to bespoke design stipulations. Boasting a stellar strength-to-mass ratio, they enable an efficacious and streamlined structural layout and assembly. Moreover, their homogeneity and standardized outlines promote expedited and precise erection, truncating labor and edifice durations.

Customization:

Product Name: CZ Purlin Roll Forming Machine

Brand Name: HC

Model Number: HC-CZ

Place of Origin: China

Certification: CE

Minimum Order Quantity: 1

Packaging Details: 40GP Container

Delivery Time: 45Days

Payment Terms: 30% deposit by T/T before manufacture, The balance to be paid before delivery.

Supply Ability: 60 Sets Per Month

Cutting Length: Can Be Set In The Control Panel

Machine Weight: 8-9T

Drive Type: Chain Drive

Warranty: 1 Year

FAQ:

Q1: What is the brand name and model number of the Purlin Roll Forming Machine?

A1: The brand name of the machine is HC, and the model number is HC-CZ.

Q2: Where is the HC Purlin Roll Forming Machine manufactured?

A2: The HC Purlin Roll Forming Machine is manufactured in China.

Q3: What kind of certification does the HC Purlin Roll Forming Machine have?

A3: The HC Purlin Roll Forming Machine has CE certification, ensuring it meets European safety, health, and environmental protection standards.

Q4: What is the minimum order quantity for the HC Purlin Roll Forming Machine?

A4: The minimum order quantity for the HC Purlin Roll Forming Machine is 1 unit.

Q5: Can you provide details about the packaging and delivery time of the HC Purlin Roll Forming Machine?

A5: The HC Purlin Roll Forming Machine is packaged in a 40GP container for safe transportation. The delivery time for the machine is approximately 45 days from the date of order confirmation.

Q6: What are the payment terms for purchasing the HC Purlin Roll Forming Machine?

A6: The payment terms for the HC Purlin Roll Forming Machine are 30% deposit by T/T before manufacture, with the balance to be paid before delivery.

Q7: How many sets of the HC Purlin Roll Forming Machine can be supplied per month?

A7: The supply ability of the HC Purlin Roll Forming Machine is 60 sets per month.
