One Click CZ Purlin Interchange Roll Forming Machine Chain Drive

3T Manual Decoiler

This part is used to support Coil.

And make the coil in a rotary way.

Bearing capacity: 3T

Inner diameter: 470-530mm

(adjustable according to demand.)

In order to avoid damage to the machine by impact when the machine is running, we have installed a brake device for you.

Feeding Table and Flattening

Guide the coil come into the correct position and passed to the roll forming machine.

Feeding Platform,Ensure smooth and precise material feed.steel plate platform, two pitching rollers, position stopping block.

The coil is guided in the correct position and passed to the roll forming.

Punching

Hydraulic punching

Punch after feeding.

The surface of the holes is smooth without burrs.

PLC will control punching position.

Shaft & Roller

One-click fully automatic CZU model and size adjustment.

Material of rollers:Bearing steel (quenched).

The polished surface and the heat treatment towards the molds also can keep the molding plate surface smooth and not easy to be marked when it is being stamped.

Cutter

 Fully automatic control and precise cutting.

Silky smooth with noiseless.

Material of blades: Cr12,quenching treatment.

Hydraulic Pump Station

It use 46# hydraulic oil.

The purpose of this pumping station is to

supply the power to the cutter and punching device.

Touch Screen Control Cabinet

The length, waist height and angle can be set by yourself.

Change models with one click.

Output Table

2 pieces.

For receiving finished products.
