Features

Specifications

Material: Galvanized Steel

Thickness: 0.5mm

Speed: 25m/min

Feature: Easy Operation

Highlight:

cold metal stud and track roll forming machine

3phases metal stud and track roll forming machine

tracking cut off stud roll former

Basic Infomation

Place of Origin: Botou Hebei China

Brand Name: HC

Certification: ISO

Payment & Shipping Terms

Packaging Details: Main machine is nude,the computer control box is packed by carton box

Delivery Time: 30days

Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment

Supply Ability: 20 sets/month

Gallery

Cold 3phases Metal Stud And Track Roll Forming Machine With Tracking Cut Off

Product Description

Metal Stud and Track Cold Roll Forming Machine

Quick Detail:

1. Suitable to process: Color steel plate

2. Width of the plate:175mm

3. Rollers: 12rows

4. Dimensions: 6.1*1.15*1.51m

5. Power: 4.5+3kw

6. Rolling material: shaft bearing steel(quenching)

7. Thickness of the plate:0.3-0.6mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control

Cold 3phases Metal Stud And Track Roll Forming Machine With Tracking Cut Off 0

Cold 3phases Metal Stud And Track Roll Forming Machine With Tracking Cut Off 1

Description:

Keel Roll Forming Machine Main parameter

No.	Main parameter of Keel Roll Forming Machine
1	Suitable to process	Color steel plate
2	Width of the plate	175 mm
3	Rollers	12 rows
4	Dimensions	610011501510mm
5	Power	4.5+3kw
6	Rolling material	shaft bearing steel(quenching)
7	Thickness of the plate	0.3-0.6 mm
8	Productivity	20m/min
9	Diameter of the roller	Φ50mm
10	Voltage	380V 50Hz 3phases
11	Material of the cutting plate	Cr12
12	Hydraulic	40#
13	Processing precision	Within 1.00mm
14	Control system	PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting

Competitive Advantage

1. CE certification

2 .ISO certification

3. working life 20 years

4. high quality steel

5. High efficiency

Cold 3phases Metal Stud And Track Roll Forming Machine With Tracking Cut Off 2
