CE Approvals Double Layer Roll Forming Machine for 0.3-0.6mm Metal Deck and Steel Tile with Mitsubishi PLC Control

CE Approvals Double Layer Roll Forming Machine for 0.3-0.6mm Metal Deck and Steel Tile with Mitsubishi PLC Control
CE Approvals Double Layer Roll Forming Machine for 0.3-0.6mm Metal Deck and Steel Tile with Mitsubishi PLC Control CE Approvals Double Layer Roll Forming Machine for 0.3-0.6mm Metal Deck and Steel Tile with Mitsubishi PLC Control CE Approvals Double Layer Roll Forming Machine for 0.3-0.6mm Metal Deck and Steel Tile with Mitsubishi PLC Control

Large Image :  CE Approvals Double Layer Roll Forming Machine for 0.3-0.6mm Metal Deck and Steel Tile with Mitsubishi PLC Control

Product Details:
Place of Origin: Botou Hebei China
Brand Name: HC
Certification: CE
Model Number: HC18/10
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: Main machine is nude, the computer control box is packed by carton box.
Delivery Time: 30days
Payment Terms: L/C,T/T
Supply Ability: 20 sets/month
Contact Now

CE Approvals Double Layer Roll Forming Machine for 0.3-0.6mm Metal Deck and Steel Tile with Mitsubishi PLC Control

Description
Highlight:

metal roll forming machine

,

sheet metal roll forming machines

CE Approvals Double Layer Roll Forming Machine For Metal Deck And Steel Tile
Machine's Feature: One machine can make two kinds of profile. Client's profile available.
Technical Specifications
Suitable Material Q235 color steel sheet; 0.3-0.6mm
Forming Speed Upper layer: 4m/min, Down layer: 20m/min
Power Requirement Main motor power: 5.5 Kw (Depend on final design)
Hydraulic station power: 5.5Kw (Depend on final design)
Material of Forming Rollers No.45 steel, plated with chrome on surface
Material of Cutter Cr12 mould steel with quench treatment, HRC58-60
Material of Shaft High quality 45# steel with heat treatment. Roller grinder milling.
Shaft Diameter 70mm
Controlling System Mitsubishi PLC & converter
Total Weight of Machine About 9500KGS
Machine's Size About 8.5m×1.8m×1.5m (Depend on final design)
Shipping 1x40GP can load one machine
Product Application
The products from this roll forming machine are widely used for roof or wall of fabrication building, such as the roof of garden, factory, hotel, exhibition center and villa, etc.
Key Advantages
  • Anti-rust roller: CNC machine tooled, plated with 0.05mm hard chrome
  • Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation
  • Cutter blade: Cr12 mould steel with quenched treatment, long life time
  • High precision: Shafts for rollers are tooled by grinding machine at least twice. Rollers are CNC processed to ensure precision performance
  • User-friendly operation: Introduced Mitsubishi PLC with touch screen. Friendly man-machine interaction
  • Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifetime services for our machines
  • All-in-house source: We are "All-in-house source" factory to ensure quality and delivery of your machines
  • Long life: Ensure our production machine's lifetime more than 15 years
Certification
CE

Tag:

sheet metal roll forming machines,

metal roll forming machine,

corrugated roll forming machine
