Product Details:
|
| High Light: | 8m/min corrugated roll forming machine,roof sheeting corrugated roll forming machine,4m/min corrugated roof sheeting machine |
||
|---|---|---|---|
4 - 8m / min Steel Silo Wall Panel Roll Forming Machine , Galvanized Sheet Metal Roll Former
Description
Corrugated roof sheet roll forming machine is widely used to produce the metal roof and wall cladding. It is becoming the most popular roof and caldding style in many countries.
The whole line of corrugated roof sheet roll forming machine is composed by decoiler(automatic or manual) for coils from 5ton to 10ton, roll forming machine include the guide and feeding device.
cutting blade drived by hydraulic power and auto stacker or manual stacker for finished products. This line can be automaticly running by inputing the length and batches into the PLC control system.
Easy operation: Directly input the data on the touch table screen.
Customers may decide the profile of products.
Quick details:
1. Thickness of raw material: 0.3-0.8mm, depends on your request.
2. Cutting of trapezoidal forming: hydraulic guide pillar cutting.
3. Color of profile sheet forming machine: blue or as your request
Specifications
| Item | Steel Roof Sheet Roll Forming Machine | |
| Coil Material | Coil width | Custom-made,1000/1200/1250mm |
| Yield Strength | 350-500 Mpa | |
| Decoiler / Uncoiler | Decoiler Type | Manual or Hydraulic or Auto Type |
| Coil Width | Max. 1250mm | |
| Steel roof forming machine | Forming Stations | 13-22 Stations (Depend on Profiles) Usually:18 Stations |
| Diameter of shaft | 76mm | |
| Cutting | Cutting type | Hydraulic Scissor cutting |
| Cutting power | 4 KW (Hydraulic station) | |
| Electrical control | Touch screen | Panasonic |
Main Components of Roof Panel Roll Forming Machine
| Decoiler / Uncoiler | 1 Unit |
| Feeding Guide | 1 Unit |
| Roof Panel Roll Forming Machine | 1 Unit |
| Hydraulic Cutting System | 1 Unit |
| Hydraulic Station | 1 Unit |
| PLC Computer Control Box | 1 Unit |
| Support Tables | 2 Units |
Working flow
Decoilel-àguide feeding-àroll forming machine-à hydraulic cutting-àoutput table
Application
Metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding, wall panel.
Product pictures
Advantages
1. We can make and design all kinds of roll forming machine according to customer’s requests.
2. This kind of machine has the best quality and the best price. It has accurate measurement and easy operating.
3. We can design and manufacture the special type machine according to the customers’ requirement and we could provide technical guiding, production, debugging and maintenance service to all customers.
