1250 mm Galvanized Sheet Metal Roll Forming Machines 5.5kw Power

1250 mm Galvanized Sheet Metal Roll Forming Machines 5.5kw Power
1250 mm Galvanized Sheet Metal Roll Forming Machines 5.5kw Power

Large Image :  1250 mm Galvanized Sheet Metal Roll Forming Machines 5.5kw Power

Product Details:
Place of Origin: Botou Hebei China
Brand Name: HC
Certification: ISO
Model Number: HC17
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 8000-29000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month

1250 mm Galvanized Sheet Metal Roll Forming Machines 5.5kw Power

Description
Type: Electric Control Standing Seam Metal Roof Machine Rollers: 19
Roller Material: No.45 Steel Warranty: 12 Month
High Light:

roof tile roll forming machine

,

roof panel roll forming machine


1250 mm Galvanized Sheet Metal Roll Forming Machines 5.5kw Power

Introduction


This cameroon aluminium zinc roof sheets roll forming machine adopts Mitsubishi PLC control system, so the operator can set parameters like sheet quantity, sheet length into the touching screen, then this machine will produce corrugated galvalume roof sheets automatically. The corrugated zinc steel roofing sheets manufactured by this roll forming machine is to give a strong and reliable ability that can perform in serious outdoor conditions. With a different thickness, these sheets are best suited for domestic roofing and walling, and are available in a range of lengths to suit roofer's needs. The versatile corrugated profile can reflect both modern and traditional architecture depending on the application.

Corrugated profile
Suitable for roofing and walling
762mm coverage width after overlap
High quality Steel construction
Available in a range of lengths


Technical Specifications Cameroun Alu-zinc Roof Sheet Corrugating Machine

Technical Items Details
Raw Material Type Aluminium & Steel Coils, PPGI, GI, PPGL
Width 1200 mm
Thickness 0.15-0.30 mm or 0.30-0.70mm
Yield Strength 235-345 MPa or specially designed for 550 MPa
Finished Products Cover width 1050 mm
Length Adjustable
Required Power Voltage 220V/380V/415V/440V
Driving Motor 5.5 KW
Cutting Motor 2.2 KW
Production Speed 900-1200 meters per hour
Coil Decoiler Type Un-powered or Powered
Capacity 5 tons
Rolling Stations 15 sets
Rolling Shaft Diameter 72 mm
Cutting Type Post-cutting
Operation System Mitsubishi PLC, transducer and touching screen
Supporting Tables 2 sets
Machine Size Around 8.5 x 1.6 x 1.5 meters
Machine Weight Around 7.8 tons


Main Components Cameroun Alu-zinc Roof Sheet Corrugating Machine

No. Items Quantity
1 Coil Decoiler 1 set
2 Roll Former Machine Direction Guilder 1 set
Rolling System 1 set
Post-cutting Device 1 set
3 Supporting Tables for Finished Products 2 sets
4 Hydraulic Station for Cutting Device 1 set
5 PLC Control Cabinet 1 set
6 Tools Box with Spare Parts 1 set





Applications:


With the timeless appeal of a corrugated profile, cladding is a strong and versatile roofing, walling and fencing material. It complements both contemporary and traditional architecture. It is available in long lengths and a range of thicknesses.

1250 mm Galvanized Sheet Metal Roll Forming Machines 5.5kw Power 01250 mm Galvanized Sheet Metal Roll Forming Machines 5.5kw Power 11250 mm Galvanized Sheet Metal Roll Forming Machines 5.5kw Power 2
