Roofing Glazed Tile Roll Forming Machine , 2 Layer Roll Form Machine Plc Control

China Roofing Glazed Tile Roll Forming Machine , 2 Layer Roll Form Machine Plc Control supplier

Large Image :  Roofing Glazed Tile Roll Forming Machine , 2 Layer Roll Form Machine Plc Control

Product Details:

Place of Origin: Botou Hebei China
Brand Name: HC
Certification: ISO/CE
Model Number: HC18-36

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: 15000-39000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month
Contact Now
Detailed Product Description
Color: Blue Type: Automatic
Control System: PLC Control Cutting Method: Hydraulic Cut
Working Speed: 8-10m/min Per Month: 30 Sets

 Roofing Glazed Tile Roll Forming Machine , 2 Layer Roll Form Machine Plc Control



No. Main Parameter of Double Layer Glazed Tile Forming Machine
1 Suitable to process Color steel plate
2 Width of the plate 1250mm
3 Rollers

Up layer:10 rows

Down layer:15 rows

4 Dimensions 9500*1550*1910mm
5 Power 4+4kw
6 Thickness of the plate 0.3-0.6mm
7 Productivity

Up layer:4m/min

Down layer:15-20m/min

8 Material of the cutting blade Cr12
9 Diameter of the roller Φ70mm
10 Weight About 6.9T
11 Voltage 380V 50Hz 3phases
15 Control system PLC control

Industrial Process And Component Specification

Alibaba China Roll Cutting Machinery Metal Roofing Double Layer Glazed Tile Forming Machine

No   Technical Specification
1 Auto Uncoiler Usage:It is used to support the steel coil and uncoil it in a turnable way. The steel coil is uncoiled by hand. Loading capacity:5T,Inner diameter: 500-508mm
2

Hydraulic System

Computer Control Cabinet

Power:4kw,Hydraulic oil: 40#

hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job.

The target piece`s length is adjustable and digit of it can be adjusted

Computed mode has two modes: automatic and manual one. The system is easy to operate and use

PLC:EURA

3 Press Form

Press Form

Material of blades: Cr12,quenching treatment

4 Shearing Mechanism

It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products.

Material of blades: Cr12,Quenching treatment

5 Auto Stacker

Start reducer quickly after finish cutting products, deliver products to hold arms by deliver rollers

Then pneumatic control stack on the store table which is movable

Pneumatic pump (power sources) is self supply.



 Roofing Glazed Tile Roll Forming Machine , 2 Layer Roll Form Machine Plc ControlRoofing Glazed Tile Roll Forming Machine , 2 Layer Roll Form Machine Plc ControlRoofing Glazed Tile Roll Forming Machine , 2 Layer Roll Form Machine Plc Control

Our Services

1. Warranty :One year,and we will provide technical support for whole life of the equipment.

2. Delivery time: Within 30 days after deposit receipt your payment

3. Guarantee period: 18months free service/ pay service all the machine life

4. Installation and training

If buyers visit our factory and check the machine, we will teach you how to install and use the machine

and also train your workers/technician face to face.

Without visiting,we will send you user manual and video to teach you to install and operate.

If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.
