Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One

Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One
Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One

Large Image :  Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One

Product Details:
Place of Origin: Botou Hebei China
Brand Name: HC
Certification: ISO/CE
Model Number: HC19/28
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 15000-39000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box.
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.
Supply Ability: 20 sets/month

Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One

Description
Color: Blue Type: Automatic
Control System: PLC Control Cutting Method: Hydraulic Cuting
Per Month: 30 Sets
High Light:

metal roll forming machine

,

sheet metal roll forming machines

Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One


Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One 0
Quick Detail:
1. Suitable to process: Color steel plate
2. Width of the plate: 1250mm
3. Rollers: 10/17 rows
4. Dimensions: 9.7*1.55*1.91m
5. Power: 4+4kw
6. Rolling material: high grade 45# steel(plated chrome on surface)
7. Thickness of the plate:0.3-0.6mm
8. Voltage: 380V 50Hz 3phases
9. Material of the cutting plate: Cr12
10. Hydraulic: 40#
11. Processing precision: Within 1.00mm
12. Control system: PLC control


Description:
 Main parameter

No.

 Main parameter of Double layer roll forming machine


1

Suitable to process

Color steel plate

2

Width of the plate

1250mm

3

Rollers

upper level :12 rows
Down level :12 rows

4

Dimensions

9700*1550*1910mm

5

Power

4+4kw

6

Rolling material

high grade 45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

20m/min

8

Diameter of the roller

Φ70mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control



Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system- cutting
Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One 1

Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One 2

Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One 3
Application
This kind of machine make two types of tile together perfectly, it has reasonable structure, beautiful appearance, with advantage of saving space, easy operate and especially welcomed by the customer  with limit area or site

Competitive Advantage
 1. CE certification
2. noiseless
3. easy operate
4. high output
5. easy maintain

Hydraulic Cutting Double Layer Steel Sheet Roof Forming Machine With 2 Profiles in One 4
